1
Engine displacement
500
2
Year
2007
3
Trim
RANGER 500 EFI 4X4 - R07RH50AF/AR/AT
4
Parts Catalog
BRAKE PEDAL
5
Parts Diagram
Parts Catalog
BRAKE LINES/MASTER CYLINDER
by
CRANKCASE
BRAKE PEDAL
1
Bolt Hex
7515319
$9,44 Unit Price incl. VAT
2
NUT-5/16-18 NYLOK-Y [INTL]
7542324
$1,56 Unit Price incl. VAT
3
NUT-3/8-24(NYLOK)-Y
7542439
$2,09 Unit Price incl. VAT
4
BUSHING PIVOT PEDAL
5433189
$7,34 Unit Price incl. VAT
5
Tube Brake Pedal Bushing
5334030
$16,79 Unit Price incl. VAT
6
PIN CLIP 14MM
7661140
$2,09 Unit Price incl. VAT
7
Pedal Brake Black
1015870067
$85,88 Unit Price incl. VAT
8
PIN-CLEVIS 1/4 X 3/4 -Y
7661843
$4,19 Unit Price incl. VAT
9
SCR-3/8-24X2 3/4HX HD CP GR5-Y
7515417
$9,44 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
