1
Engine displacement
500
2
Year
1995
3
Trim
500 CARB - 0952764
4
Parts Catalog
ENGINE MOUNTING 500 CARB 0952764 (4929192919C001)
5
Parts Diagram
Parts Catalog
DRIVEN CLUTCH ASSEMBLY 500 CARB 0952764 (4929192919B014)
by
EXHAUST SYSTEM 500 CARB 0952764 (4929192919C002)
ENGINE MOUNTING 500 CARB 0952764 (4929192919C001)
1
2
3
4
5
6
7
9
10
11
12
12
13
13
14
15
16
17
18
19
20
21
21
22
23
24
25
26
27
28
29
29
29
29
29
29
29
30
30
31
32
33
34
35
1
BOLT(10)
7512565
$36,74 Unit Price incl. VAT
2
WASHER-7/16-INT LK-(1222)-Z [ACCESSORY]
7575202
$9,44 Unit Price incl. VAT
3
WASHER CLUTCH RETAINER
5010278
5010287
$18,89 Unit Price incl. VAT
4
O-RING CLUTCH BOLT
5410507
$2,09 Unit Price incl. VAT
5
SPACER CLUTCH BOLT
5020513
$60,89 Unit Price incl. VAT
6
CAP PRESSURE
2511155
Not Available
7
SPARKPLUG RN3C(8)
3070166
$7,34 Unit Price incl. VAT
9
ENG.(S.B.)EC50PL-05 [No Longer Available]
3084621
Not Available
10
HANDLE RECOIL Substituted by 5431499-070
5431499
$26,24 Unit Price incl. VAT
11
SCREW
7512530
$10,49 Unit Price incl. VAT
12
WASHER FLAT
7555740
$3,14 Unit Price incl. VAT
13
MOUNT ENGINE
5410390
Not Available
14
TUBE SPACER
5333354
Not Available
15
NUT FLANGE
7542522
$10,49 Unit Price incl. VAT
16
PLATE ENG.MT.
5222867
Not Available
17
WASHER LOCK(10)
7553101
$7,34 Unit Price incl. VAT
18
BOLT
7512539
$7,34 Unit Price incl. VAT
19
NUT FLEXLOC
7542411
$6,29 Unit Price incl. VAT
20
WASHER
7555721
$2,09 Unit Price incl. VAT
21
MOUNT
3110022
Not Available
22
NUT JAM [ACCESSORY]
7542432
$7,34 Unit Price incl. VAT
23
LIMITER TORQUE BLK.
1011930067
Not Available
24
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
25
STOP
3110023
Not Available
26
WASHER(10) Substituted by 7555806
7555720
7555806
$1,56 Unit Price incl. VAT
27
NUT-3/8-24(NYLOK)-Y
7542439
$2,09 Unit Price incl. VAT
28
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
29
HOSE CLAMP RED
7080003
$2,09 Unit Price incl. VAT
30
FUEL LINE-1/4 ID (SVC) 600 CM [BULK]
8450040600
$136,49 Unit Price incl. VAT
31
CABLE THROTTLE W/OIL
7080520
Not Available
32
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
33
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
34
FILTER FUEL (10)
2530008
$10,49 Unit Price incl. VAT
35
VALVE FUEL SHUT-OFF
7052039
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
