TUNNEL AND SEAT ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE DELUXE 09 (4928902890A006)
5
Parts Diagram
Parts Catalog
BLOWER HOUSING RECOIL ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE D (4928902890D009)
by
NOSEPAN CONSOLE ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE DELUX (4928902890A008)
TUNNEL AND SEAT ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE DELUXE 09 (4928902890A006)
1
CAP GAS W/GAUGE
2511245
Not Available
2
GASKET GAS CAP
5810513
$15,74 Unit Price incl. VAT
3
SEAT ASM (LITE) [No Longer Available] (Lite)
2681764
Not Available
3
SEAT ASM (LITE DLX.) (Deluxe)
2681766
Not Available
3
SEAT CUSHION (STAR/LITE#94) (Lie StarLite)
2681678
Not Available
4
COVER SEAT (StarLite)
2681767
Not Available
4
COVER SEAT (STAR/LITE#94) (Lite Star)
2681679
Not Available
4
COVER SEAT (LITE) (Lite)
2681765
Not Available
5
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
6
WASHER-.312 X .734 X .065-Z
7558302
$3,14 Unit Price incl. VAT
7
SCREW(10)
7511840
Not Available
8
LENS TAILLIGHT
5430423
Not Available
9
HOUSING TAILLIGHT Substituted by 5433341 (See Drwg. A)
5431545
Not Available
10
BULB BRAKELIGHT
4030045
Not Available
11
HARNESS TAILLIGHT
2460399
Not Available
12
SCREW(10)
7515111
$13,64 Unit Price incl. VAT
13
WASHER NYLON
7555798
$1,56 Unit Price incl. VAT
14
FUELPICKUP W/STRAINER
7052037
7052301
$26,24 Unit Price incl. VAT
15
RING COMPRESSION
7080402
$3,14 Unit Price incl. VAT
16
TANK FUEL
2511215
Not Available
16
TANK FUEL (LITE GT) Substituted by 2520179
2511214
Not Available
17
FITTING OUTLET DOUBLE
7052023
$36,74 Unit Price incl. VAT
17
FITTING OUTLET (StarLite GT)
7052056
$11,01 Unit Price incl. VAT
18
CLAMP-HOSE (LARGE GREEN)
7080307
$1,56 Unit Price incl. VAT
19
HOSE [BULK SVC]
84500031525
$136,49 Unit Price incl. VAT
20
FITTING 90 DEGREE
7052095
$9,44 Unit Price incl. VAT
20
FITTING (10)
7052077
Not Available
21
DESC NOT_AVAILABLE
8360009175
Not Available
22
RIVET (50)
7621477
$2,09 Unit Price incl. VAT
23
GUIDE RECOIL
5431385
$19,94 Unit Price incl. VAT
24
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
25
BRKT ROPE GUIDE BLK. (StarLite GT)
5222687067
$89,24 Unit Price incl. VAT
26
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
27
BRKT STAND BLK.
5220520067
Not Available
28
RIVET-CHERRY Q-3/16X.325-Z
7621453
Not Available
29
GROMMET RUBBER
5410021
Not Available
30
TUNNEL ASM (LITE) (Incl. 33 44 & 48)
1011881
Not Available
31
BRKT CONSOLE/SEAT MT.
5222452067
$41,04 Unit Price incl. VAT
32
SCR-RHCAR-1/4-20X0.75 GR5 ZY3
7512193
$4,19 Unit Price incl. VAT
33
NUT SPEED
7670021
$10,49 Unit Price incl. VAT
34
STRAP GASTANK BLK.
5222330067
Not Available
35
CUSHION TANK H.D.
5420126
Not Available
36
RIVET (50)
7661836
$1,04 Unit Price incl. VAT
37
DECAL TRACK/SEAT(CPSC) (Black)
7074254
Not Available
38
BUMPER REAR
5224480067
Not Available
39
POP RIVET(50)
7621418
$2,09 Unit Price incl. VAT
40
FLAP SNOW SILVER Substituted by 5410394-1106 (400)
5410394
5410394-1038
$194,24 Unit Price incl. VAT
41
SCREW(10)
7512252
Not Available
42
REFLECTOR RED
2670070
$15,95 Unit Price incl. VAT
43
RIVET (50)
7661837
$1,04 Unit Price incl. VAT
44
BRKT RH R.SUSP BLK.
1011780067
Not Available
44
BRKT LH R.SUSP BLK.
1011779067
Not Available
45
FOOTREST ASM LH
1011830
Not Available
45
FOOTREST ASM RH (STARLITE)
1011826
Not Available
46
SUPPORT LH TRLG.ARM BLK.
1011792067
Not Available
46
SUPPORT RH TRLG.ARM BLK.
1011793067
Not Available
47
BRKT FR.SUSP BLK.
5220542067
Not Available
48
PAD AIR BOX
5810502
Not Available
49
BUSHING SNAP(10)
7080404
Not Available
50
BULKHEAD (STARLITE) (StarLite GT)
1011885067
Not Available
50
BULKHEAD BLK (94LITE) Substituted by 1012587-067 (Lite GT)
1011983067
Not Available
51
PLUG-HOLE
7080416
$12,59 Unit Price incl. VAT
52
PLUG-HOLE
7080398
$10,49 Unit Price incl. VAT
53
MOUNT RADIUS ROD Substituted by 5630924
5130759
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
