1
Engine displacement
0
2
Year
1994
3
Trim
W948040 - W948040
4
Parts Catalog
STEERING
5
Parts Diagram
Parts Catalog
FRONT BRAKE SPORTSMAN 4X4 W948040 (4926842684B006)
by
STEERING POST ASSEMBLY SPORTSMAN 4X4 W948040 (4926842684B008)
STEERING
1
PAD HANDLEBAR
5810379
$73,49 Unit Price incl. VAT
2
BOLT(10) Substituted by 7515197
7512286
7515197
$2,09 Unit Price incl. VAT
3
MOUNT HDLBR. PAD Substituted by 5245051
5220946
$9,23 Unit Price incl. VAT
4
BLOCK HANDLEBAR Substituted by 5630187-067 (SS)
5630187
$8,39 Unit Price incl. VAT
5
TUBE HDLBR BLACK Substituted by 5242988-067
5224316067
Not Available
6
DECAL O#RIDE SW.(4X4) Substituted by 7076273
7072827
Not Available
7
MASTER CYL.ASM. Substituted by 2050073
2050062
2050073
$456,74 Unit Price incl. VAT
8
SWITCH LH H#BAR(ATV)
4110157
Not Available
9
GRIP HANDLEBAR
5431030
5433834-070
$52,49 Unit Price incl. VAT
10
SCREW
2010055
Not Available
11
BRACKET SPEEDO
5222269067
$25,08 Unit Price incl. VAT
12
CLIP(10)
7080278
$4,71 Unit Price incl. VAT
13
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
14
HAIRPIN COTTER(10) (Indy Lite)
7660701
$3,66 Unit Price incl. VAT
15
PLATE MTG (SPEEDO) (Indy Lite)
5211189
$19,94 Unit Price incl. VAT
16
SPACER SPEEDO.MTG. (Indy Lite)
5810442
Not Available
17
CABLE SPEEDO (ATV) Substituted by 3280216
3280184
Not Available
18
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
19
SEAL SPEEDO.CABLE
3280132
Not Available
20
WASHER(10)
7555725
Not Available
21
BOLT(10)
7515378
Not Available
22
ADAPTER DRIVE ATV Substituted by 3280218
3280187
Not Available
22
ADAPTER DRIVE (1:1.2) ATV Substituted by 3280219
3280128
Not Available
23
NUT-5/16-18 NYLOK-Y [INTL]
7542324
$1,56 Unit Price incl. VAT
24
KEY SPEEDO.DRIVE
3280165
$29,28 Unit Price incl. VAT
25
SEAL ANGLE DRIVE
3280164
Not Available
26
BUSHING SPEEDO.DRIVE
5020741
$14,48 Unit Price incl. VAT
27
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
28
BULB TAILLIGHT(10)
4030015
$8,39 Unit Price incl. VAT
29
HARNESS SPEEDO
2460387
Not Available
30
MOUNT SPEEDOMETER
5410546
Not Available
31
SPEEDOMETER ATV
3280129
Not Available
31
SPEEDOMETER (ATV)
3280181
Not Available
32
THROTTLE CONTROL AWD PRD.EASY (See pg. A24)
2010149
Not Available
33
WASHER [INTL]
7558301
$2,09 Unit Price incl. VAT
34
BOLT (10)
7512265
$7,34 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
