STARTING MOTOR 2X4 350L W937539 (4924032403037A)
5
Parts Diagram
Parts Catalog
RECOIL STARTER 2X4 350L W937539 (4924032403036A)
by
STARTING MOTOR 2X4 350L W937539 (4924032403037A)
17
18
19
20
21
1
STARTER MOTOR ASM. Substituted by 3085393 (Incl.8-17) (#J# Model Only)
3084403
Not Available
2
NUT FLANGE(10)
3083649
$7,34 Unit Price incl. VAT
3
BRUSH COMPL.2-POLE *
3084406
$230,99 Unit Price incl. VAT
4
RING RUBBER
3084405
Not Available
5
O-RING
3084408
Not Available
6
BOLT THROUGH (#J# Model Only)
3084407
Not Available
7
BRACKET Substituted by 3086780
3084214
Not Available
8
BOLT FLANGE(10) Substituted by 3087035
3083568
7520710
$7,34 Unit Price incl. VAT
9
WASHER SET
3083754
$4,19 Unit Price incl. VAT
10
ARMATURE ASM. *
3084404
$333,89 Unit Price incl. VAT
11
O RING
3083934
Not Available
12
BALL BEARING
3083777
$54,59 Unit Price incl. VAT
13
O RING
3083741
Not Available
14
WASHER GEARSHAFT Substituted by 7555908
3083737
7556994
$6,29 Unit Price incl. VAT
15
GASKET
3083835
Not Available
16
BOLT FLANGE Substituted by 3086781
3084215
$9,44 Unit Price incl. VAT
17
CLIP
3084409
$13,64 Unit Price incl. VAT
18
SPRING RETURN
3084410
$3,98 Unit Price incl. VAT
19
GEAR SHAFT ASM. Substituted by 3085394
3083647
$456,74 Unit Price incl. VAT
20
SPRING WEIGHT
3084411
$25,08 Unit Price incl. VAT
21
CLIP
3084412
$17,84 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
