1
Engine displacement
500
2
Year
2006
3
Trim
SPORTSMAN 500 EFI - A06MH50AQ
4
Parts Catalog
WINCH
5
Parts Diagram
Parts Catalog
WATER PUMP
by
MAGNETO
WINCH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
2
3
4
5
5
5
6
7
8
9
10
11
12
13
14
15
16
16
17
17
18
1
SCR-M6X1.0X40 HX/SOC/CP-Y/D
7510005
$9,44 Unit Price incl. VAT
2
Switch Handlebar Winch
4011732
Not Available
3
Spacer (If built after 10/08/02)
5334334
$36,74 Unit Price incl. VAT
4
Harness Winch Kit Pre Wire
2410898
$173,24 Unit Price incl. VAT
5
Asm. Winch [Incl. 11 13 14 15 16 17]
2410869
Not Available
6
SCR-5/16-18X3/4 TFM HW T/R-Y
7515399
$2,09 Unit Price incl. VAT
7
Panel Bumper
5436991070
Not Available
8
Bracket Switch Winch
5250830
Not Available
9
Kit Contactor
2875995
Not Available
10
BOLT(10)
7512247
Not Available
11
Plate Winch Mount
5250828
Not Available
12
Kit Hook and Latch
2875998
Not Available
13
Kit Cable
2876000
Not Available
14
Bracket Fairlead Mount
5250829
Not Available
15
Kit Fairlead Roller
2875997
Not Available
16
Harness Winch Motor
2410896
$112,86 Unit Price incl. VAT
17
Winch 2500 lbs
5631959
Not Available
18
Harness Winch Contactor
2410897
$112,86 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
