1
Engine displacement
500
2
Year
2006
3
Trim
SPORTSMAN 500 EFI - A06MH50AQ
4
Parts Catalog
FUEL TANK
5
Parts Diagram
Parts Catalog
DECALS
by
CONTROLS
FUEL TANK
1
2
3
4
4
5
6
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
19
20
1
Cap Gas Tank
5433687
5450389
$36,74 Unit Price incl. VAT
2
Gasket
5812123
$10,49 Unit Price incl. VAT
3
Vent Tank
5431053
$47,24 Unit Price incl. VAT
4
HOSE-POLY CLEAR 3/16 OD 1/8 ID
8360009600
$83,99 Unit Price incl. VAT
5
SCR-1/4-20X1 HX/WH/TAP/R GR5-Y
7515179
$4,19 Unit Price incl. VAT
6
Bracket Mounting Rear RH
5247185
$73,49 Unit Price incl. VAT
6
Bracket Mounting Rear LH
5247184
Not Available
7
Seal Foam
5812265
$52,49 Unit Price incl. VAT
8
Tank Fuel
2520437
$1 658,99 Unit Price incl. VAT
9
Foil [If built after 10/5/05]
5813044
$36,74 Unit Price incl. VAT
10
Foil
5813045
$36,74 Unit Price incl. VAT
11
Asm. Fuel Line Tank to Filter
2520443
$89,24 Unit Price incl. VAT
12
SCR-TFHFL-1/4-20X0.75 CHS ZY3
7512232
$2,09 Unit Price incl. VAT
13
Mount Fuel Filter
5436013
$16,79 Unit Price incl. VAT
14
Filter Fuel
2520464
$83,99 Unit Price incl. VAT
15
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
16
GROMMET-ELECTRIC SHOCK WIRE(10)
5411774
Not Available
17
Asm. Fuel Line Filter to Rail
2520543
$136,49 Unit Price incl. VAT
18
FITTING T
7052048
$7,34 Unit Price incl. VAT
19
VENT CHECKVALVE
7051011
Not Available
20
LINE FUEL [BULK SVC]
8450061600
$115,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
