1
Engine displacement
0
2
Year
1989
3
Trim
TRAIL BOSS 4X4 - W898127
4
Parts Catalog
Control Assembly (4916351635017A)
5
Parts Diagram
Parts Catalog
STEERING ASSEMBLY (4916351635015A)
by
STRUT ASSEMBLY (4916351635019A)
Control Assembly (4916351635017A)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
39
40
41
42
43
44
45
45
1
WASHER BAFFLE(10)
1930662
Not Available
2
BAFFLE Substituted by 1930673
1930661
Not Available
3
BOLT BRAKE LEVER(10)
7512287
Not Available
4
SEAL SIGHT GLASS
1930660
Not Available
5
GLASS SIGHT Substituted by 2200345
1930659
Not Available
6
CLAMP MASTER CYL.
5630342
Not Available
7
BRKT O#RIDE SW.(4X4)
5222317
Not Available
8
SCREW SOCKET HEAD
7512290
$9,44 Unit Price incl. VAT
9
SWITCH O#RIDE REV. Substituted by 2200342
4110088
Not Available
10
WASHER(10)
7555708
$7,34 Unit Price incl. VAT
11
SPRING COMPRESSION (10)
7041203
$52,49 Unit Price incl. VAT
12
U PACKING SEAL
5410164
$17,84 Unit Price incl. VAT
13
PISTON MASTER CYL.
5020520
Not Available
14
O RING-.549X.755X1.03
5410163
$3,14 Unit Price incl. VAT
15
SEAL OIL
3610022
Not Available
16
BUSHING BRAKE LEVER
5332931
Not Available
17
LEVER BRAKE (ATV) Substituted by 2200347
5630343
Not Available
18
NUT(10)
7542124
7542122
$2,09 Unit Price incl. VAT
19
SCREW SEMS(10)
7512020
$4,19 Unit Price incl. VAT
20
BUSHING PK.BRAKE LEVER
5020545
Not Available
21
LEVER PARKING BRAKE
5222310
Not Available
22
SPRING PK.BRAKE
7041229
$62,99 Unit Price incl. VAT
23
HSG.W/SIGHT GLASS Substituted by 5130772
2200313
Not Available
24
GASKET MASTER CYL.
5410527
$13,64 Unit Price incl. VAT
25
COVER MASTER CYL.
5630338
Not Available
26
SCREW(10)
7512016
Not Available
27
THROTTLE CONTROL ASM. Substituted by 2010091 (Incl. 39-45)
2010072
Not Available
28
CABLE THROTTLE CONTROL Substituted by 7080531
7080375
Not Available
29
LINE BRAKE UP. W/FTGS. Substituted by 1930748
1930633
1930748
$167,99 Unit Price incl. VAT
30
LINE BRAKE LH.FRT W/FTGS. Substituted by 1930752
1930631
$167,99 Unit Price incl. VAT
31
LINE BRAKE RH FRT. Substituted by 1930753
1930634
$167,99 Unit Price incl. VAT
32
LINE BRAKE R. W/FTGS.
1930632
Not Available
33
FITTING INV.FLARE CROSS Substituted by 7052044
7052049
Not Available
34
PAD GAS TANK [No Longer Available]
5850040
Not Available
35
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
36
MASTER CYL. ASM. Substituted by 2050046 (Incl. 1-5 10-23)
1930651
2050073
$456,74 Unit Price incl. VAT
37
SW. #DEMAND 4 DRIVE#
4110082
Not Available
38
BRKT SWITCH
5222167
Not Available
39
SCREW BUTTON HEAD
2010079
Not Available
40
CAP
2010080
Not Available
41
PACKING THROTTLE
2010081
Not Available
42
PLATE
2010075
Not Available
43
HOLDER
2010078
$23,09 Unit Price incl. VAT
44
BOLT HEX.
2010076
Not Available
45
SCREW SEMS(10)
2010077
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
