1
Engine displacement
0
2
Year
1997
3
Trim
EURO WIDETRAK LX - E972065
4
Parts Catalog
ENGINE MOUNTING WIDETRAK LX 0972065 AND EUROPEAN WIDETRAK LX E972065 (4938223822C002)
5
Parts Diagram
Parts Catalog
DRIVEN CLUTCH WIDETRAK LX 0972065 AND EUROPEAN WIDETRAK LX E972065 (4938223822C001)
by
EXHAUST SYSTEM WIDETRAK LX 0972065 AND EUROPEAN WIDETRAK LX E972065 (4938223822C003)
ENGINE MOUNTING WIDETRAK LX 0972065 AND EUROPEAN WIDETRAK LX E972065 (4938223822C002)
1
2
3
4
5
6
7
8
9
10
10
10
10
10
10
10
10
11
11
12
13
14
15
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
30
30
30
31
32
33
1
2
3
4
5
6
7
8
9
10
10
10
10
10
10
10
10
11
11
12
13
14
15
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
30
30
30
31
32
33
1
BOLT(10)
7512565
$36,74 Unit Price incl. VAT
2
WASHER-7/16-INT LK-(1222)-Z [ACCESSORY]
7575202
$9,44 Unit Price incl. VAT
3
WASHER CLUTCH RETAINER
5010278
5010287
$18,89 Unit Price incl. VAT
4
O-RING CLUTCH BOLT
5410507
$2,09 Unit Price incl. VAT
5
SPACER CLUTCH BOLT
5020513
$60,89 Unit Price incl. VAT
6
SPARKPLUG RN3C(8)
3070166
$7,34 Unit Price incl. VAT
7
ENG.(S.B.)EC50PL-16/19/20 [No Longer Available]
3085397
Not Available
8
HANDLE RECOIL Substituted by 5431499-070
5431499
$26,24 Unit Price incl. VAT
9
SCREW
7512530
$10,49 Unit Price incl. VAT
10
WASHER(10) (Bottom Left Side Only)
7555929
Not Available
10
WASHER FLAT
7555740
$3,14 Unit Price incl. VAT
11
MOUNT ENGINE
5410390
Not Available
12
TUBE SPACER
5333354
Not Available
13
NUT FLANGE
7542522
$10,49 Unit Price incl. VAT
14
PLATE MOTOR MT.
5240263
Not Available
15
WASHER LOCK(10)
7553101
$7,34 Unit Price incl. VAT
16
BOLT
7512539
$7,34 Unit Price incl. VAT
17
MOUNT ENGINE
3110061
$125,99 Unit Price incl. VAT
18
WASHER
7555915
$6,29 Unit Price incl. VAT
19
NUT-3/8-16 FLEXLOCK THIN-Y
7547008
$11,54 Unit Price incl. VAT
20
NUT-HEX-3/8-16 A ZTB NYL
7542451
$2,09 Unit Price incl. VAT
21
LIMITER TORQUE
1012048067
$62,99 Unit Price incl. VAT
22
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
23
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
24
STOP TORQUE
3110063
$47,24 Unit Price incl. VAT
25
WASHER(10) Substituted by 7555806
7555720
7555806
$1,56 Unit Price incl. VAT
26
NUT-3/8-16 HX THIN-Y
7542414
$9,44 Unit Price incl. VAT
27
HOSE-POLY CLEAR 3/16 OD 1/8 ID
8360009600
$83,99 Unit Price incl. VAT
28
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
29
CABLE THROTTLE W/OIL
7080554
$120,74 Unit Price incl. VAT
30
HOSE CLAMP RED
7080003
$2,09 Unit Price incl. VAT
31
FILTER FUEL (10)
2530008
$10,49 Unit Price incl. VAT
32
VALVE FUEL SHUT-OFF (Deluxe)
7052060
Not Available
33
FUEL LINE-1/4 ID (SVC) 600 CM [BULK]
8450040600
$136,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
