1
Engine displacement
autre
2
Year
2015
3
Trim
2011- KTM 690 HUSKY 511 AND RH SIDE DRIVE MODELS (LEGACY MODELS)(2011- KTM/HUSKY) - 2011-2015 KTM/
4
Parts Catalog
FRONT TORQUE ARM
5
Parts Diagram
Parts Catalog
BRAKES, BRAKE LINE AND CALIPER
by
STEERING, SKI ASM.
FRONT TORQUE ARM
1
1
1
2
2
3
4
5
6
6
7
7
8
9
10
11
11
12
13
13
13
14
14
14
14
15
16
17
18
18
19
1
1
1
2
3
4
5
6
7
8
1
BUSHING-LWR TORQUE ARM
5453939
$11,54 Unit Price incl. VAT
2
GREASE ZERK [2011-2015]
7082299
$6,29 Unit Price incl. VAT
3
SET SCREW 5/16# [2015]
7520678
$6,29 Unit Price incl. VAT
4
ADJUSTMENT COLLAR FLEX ARM [2015]
2206705
$13,64 Unit Price incl. VAT
5
SNAP RING [2015]
7710864
$2,09 Unit Price incl. VAT
6
FRONT ARM [2011-2013 ST/LT]
2207077
Not Available
6
FLEX ARM FRONT [2014-2015 ST/LT]
2206926
Not Available
7
SHAFT-UPPER ARM [2015]
2206861
$78,74 Unit Price incl. VAT
7
ASM-SHAFT FRONT FLEX ARM [2015]
2206762
Not Available
8
BOLT. 3/8”X1-1/4” [2011-2015]
7512405
$6,29 Unit Price incl. VAT
9
WASHER 3/8# LOCK [2011-2015]
7557042
7552603
$1,56 Unit Price incl. VAT
10
WASHER 3/8 FLAT [2011-2015]
7557035
$6,29 Unit Price incl. VAT
11
SHAFT-UPPER ARM [2015]
2206861
$78,74 Unit Price incl. VAT
11
SUSPENSION REAR UPPER CROSS SHAFT [2011-2015]
2206862
$99,74 Unit Price incl. VAT
12
SHOCK-FRONT [2011-2015]
2206818
Not Available
13
SPRING 200 LB. RATE. (FACTORY RATE) [2011-2015]
2206955
$167,99 Unit Price incl. VAT
13
SPRING 250 LB. RATE [2011-2015]
2206958
$155,39 Unit Price incl. VAT
13
SPRING 300 LB. RATE [2011-2015]
2206959
$155,39 Unit Price incl. VAT
14
SPHERICAL BUSHING-LOWER SHOCK [2015]
2206700
$9,44 Unit Price incl. VAT
14
BUSHING-SHOCK
5453940
$9,44 Unit Price incl. VAT
15
O-RING
5416266
$2,09 Unit Price incl. VAT
16
COLLAR-FRONT SHOCK [2011-2015]
2206936
$41,99 Unit Price incl. VAT
17
SET SCREW
7520679
$6,29 Unit Price incl. VAT
18
ASM-LOWER FRONT SHOCK SHAFT [2011-2014]
2206939
Not Available
18
ASM-LOWER FRONT SHOCK SHAFT [2015]
2206767
$57,63 Unit Price incl. VAT
19
SHOCK-UPPER SPACERS [2015]
2206889
$41,99 Unit Price incl. VAT
20
BUSHING-LWR TORQUE ARM
5453939
$11,54 Unit Price incl. VAT
20
BUSHING-SPHERICAL LOWER ARM [2015]
2206701
$188,99 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
