REAR SUSPENSION TORQUE ARM
5
Parts Diagram
Parts Catalog
CHASSIS, TUNNEL ASM.
by
CHASSIS, FRAME
REAR SUSPENSION TORQUE ARM
1
2
18
4
5
5
6
16
8
8
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22
2
24
25
26
27
28
29
30
31
32
1
2
18
4
5
6
16
8
9
10
1
2
18
1
WASHER 3/8 FLAT [2011-2015]
7557035
$6,29 Unit Price incl. VAT
2
WASHER 3/8# LOCK [2011-2015]
7557042
7552603
$1,56 Unit Price incl. VAT
3
BOLT. 3/8”X1-1/4” [2011-2015]
7512405
$6,29 Unit Price incl. VAT
4
WHEEL 5.625 [2011-2015]
2206849
$62,46 Unit Price incl. VAT
5
O-RING
5416266
$2,09 Unit Price incl. VAT
6
SHOCK REAR [2011-2015]
2206820
Not Available
7
BUSHING-SHOCK
5453940
$9,44 Unit Price incl. VAT
8
SPRING 200 LB. RATE. (FACTORY RATE) [2011-2015]
2206955
$167,99 Unit Price incl. VAT
8
SPRING 250 LB. RATE [2011-2015]
2206958
$155,39 Unit Price incl. VAT
8
SPRING 300 LB. RATE [2011-2015]
2206959
$155,39 Unit Price incl. VAT
9
COLLAR REAR SHOCK [2011-2015]
2206935
$36,74 Unit Price incl. VAT
10
SHAFT REAR SHOCK [2011-2015]
2206942
$73,49 Unit Price incl. VAT
11
SET SCREW
7520679
$6,29 Unit Price incl. VAT
12
MH REAR SUSPENSION ARM ASSEMBLY [2011-2015][INCL. 12-29]
2206768
$996,44 Unit Price incl. VAT
13
SLIDE-T BASE [2015]
2206697
$141,74 Unit Price incl. VAT
13
SLIDE-T [2011-2014][INCL. 26]
2206938
$141,74 Unit Price incl. VAT
14
SLIDE BUSHING [2011-2015]
2206712
$9,44 Unit Price incl. VAT
15
BACK ARM UPPER BUSHING [2011-2015]
2206947
Not Available
16
BUSHING-SHOCK
5453940
$9,44 Unit Price incl. VAT
17
MOUNTAIN TAMER DECAL – WHITE [2011-2015]
2206937
Not Available
18
BOLT. 3/8”X1-1/4” [2011-2015]
7512405
$6,29 Unit Price incl. VAT
19
GREASE ZERK [2011-2015]
7082299
$6,29 Unit Price incl. VAT
20
SNAP RING [2011-2015]
7710863
$7,34 Unit Price incl. VAT
21
WIPER SEAL [2011-2015]
5416274
Not Available
22
SCREW. 3/8” [2011-2015]
7520671
$6,29 Unit Price incl. VAT
23
WASHER 3/8# LOCK [2011-2015]
7557042
7552603
$1,56 Unit Price incl. VAT
24
WASHER 1” SPRING [2011-2015]
7557050
$7,34 Unit Price incl. VAT
25
SUSPENSION REAR UPPER CROSS SHAFT [2011-2015]
2206862
$99,74 Unit Price incl. VAT
26
SLIDE-T SHAFT [2015]
2206874
Not Available
27
3/4” LOWER CROSS SHAFT [2011-2015]
2206941
$73,49 Unit Price incl. VAT
28
SLIDE-T TUBE SPACER. 3-19/32” [2011-2015]
2206943
$23,09 Unit Price incl. VAT
29
WASHER. LIMITER STRAP/SLIDE STOP WASHER [2011-2015]
7557046
$17,84 Unit Price incl. VAT
30
SUSPENSION REAR ARM [2011-2015][INCL. 13 14 16 18 20]
2206761
Not Available
31
BOLT. 3/8” [2011-2015]
7520636
$7,34 Unit Price incl. VAT
32
NUT. NYLOCK 3/8” [2011-2015]
7547869
$6,29 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
