1
Engine displacement
500
2
Year
1997
3
Trim
SPORTSMAN 500 - W97CH50A
4
Parts Catalog
RECOIL STARTER
5
Parts Diagram
Parts Catalog
INLET EXHAUST
by
MAGNETO
RECOIL STARTER
1
2
3
4
5
6
7
7
8
8
9
10
11
12
13
14
14
15
1
2
3
4
5
6
7
7
8
8
9
10
11
12
13
14
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
REEL STARTER
3084822
$167,99 Unit Price incl. VAT
2
SPRING RETURN
3083463
$8,39 Unit Price incl. VAT
3
RATCHET
3083378
$36,74 Unit Price incl. VAT
4
SPRING FRICTION
3083379
$52,49 Unit Price incl. VAT
5
PLATE FRICTION
3084744
Not Available
6
BOLT&WASHER ASM.
3085266
Not Available
7
PLUG Substituted by 3086749
3083453
Not Available
8
GASKET
3082956
$9,44 Unit Price incl. VAT
9
BUSHING STARTER
3083669
Not Available
10
Spring Power
3083185
$52,80 Unit Price incl. VAT
11
BUSH
3084750
$13,64 Unit Price incl. VAT
12
GASKET RECOIL
3084933
Not Available
13
BOLT FLANGE(10)
3084877
Not Available
14
CASE STARTER Substituted by 3085405 (Incl. 11)
3085406
Not Available
14
RECOIL ASM. Substituted by 3085652 (Incl. 1-6 9-11 14 15)
3085405
Not Available
15
ROPE ASM
3085083
$73,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
