1
Engine displacement
570
2
Year
2013
3
Trim
RZR 570 EFI INTL - R13VH57FX
4
Parts Catalog
FUEL TANK
5
Parts Diagram
Parts Catalog
by
PASSENGER GRAB BAR
FUEL TANK
1
BRACKET TANK REAR
5253844
$83,99 Unit Price incl. VAT
2
SCR-M6X1.0X20 HXHD FLG TDFM BK
7518529
$2,09 Unit Price incl. VAT
3
PAD-BATTERY NOT SHOWN
5810290
5810290-CO
$13,64 Unit Price incl. VAT
4
Asm. Fuel Tank [Incl. Pump]
2521204
$1 742,99 Unit Price incl. VAT
4
Kit Fuel Pump [Incl. Pump Gasket Nut Alcohol Wipe Instructions]
2204403
$698,24 Unit Price incl. VAT
5
CLIP ROUTING
7670109
$4,19 Unit Price incl. VAT
6
Bracket Tank Front
5253884
$115,49 Unit Price incl. VAT
7
ASM. FUEL LINE RAIL TO TANK
2521252
$209,99 Unit Price incl. VAT
8
T-CLIP T15
7081689
$13,64 Unit Price incl. VAT
9
CABLE-TIE DIA14-45MM DUAL-LOOP
7081807
$14,69 Unit Price incl. VAT
10
CAP-GAS TANK
5439075
$47,24 Unit Price incl. VAT
11
LINE VENT [BULK SVC]
8450126104
$62,99 Unit Price incl. VAT
12
CLAMP-HOSE (LARGE GREEN)
7080307
$1,56 Unit Price incl. VAT
12
CLAMP
7080236
$3,14 Unit Price incl. VAT
13
CLIP ROSEBUD
4020139
$9,44 Unit Price incl. VAT
14
SCR-10-24X1.25TFM PN TRX TRI-Y
7512025
$9,44 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
