FRAME ASSEMBLY W/ RACKS 350 4X4 / W928139 (4922832283003A) FOR TRAIL BOSS 350L 4X4

BODY FRAME 350 4X4 / W928139 (4922832283001A)

FRONT DRIVE ASSEMBLY 350 4X4 / W928139 (4922832283010A)

Screw

7515304

$10,49 Unit Price incl. VAT

WASHER-.328X1.25X16GA FL-Y

7555716

$3,14 Unit Price incl. VAT

BUSHING-.459 X.625 X.75

5010192

$12,59 Unit Price incl. VAT

DAMPENER

5410241

5412508

$9,44 Unit Price incl. VAT

BRKT LH SUPPORT RACK Substituted by 5243468-067

5220899067

Not Available

BRKT RH SUPPORT RACK Substituted by 5243469-067

5220901067

Not Available

WASHER-.344X.688X.063 FL-Y

7558402

$1,56 Unit Price incl. VAT

SUPPORT R.FENDER

5220902067

$73,49 Unit Price incl. VAT

WASHER RUBBER

5410436

$3,14 Unit Price incl. VAT

NUT-5/16-18 NYLOK-Y [INTL]

7542324

$1,56 Unit Price incl. VAT

FRAME SQUARE(4X4-350) [No Longer Available]

1040224067

Not Available

PAD RACK MOUNTING

5810455

$6,29 Unit Price incl. VAT

SCREW(10)

7512252

Not Available

HEADLIGHT ASM.

4032058

Not Available

SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]

*******

Not Available

BULB

4032059

Not Available

GUARD STONE

4032044

Not Available

SCREW

7512307

$7,34 Unit Price incl. VAT

DECAL F.SUSP.

7073455

Not Available

RACK FRT.BLK.

2670137067

Not Available

PIN COTTER

7661401

$1,56 Unit Price incl. VAT

SCREW(10)

7515355

Not Available

NUT NYLOK(10)

7542327

$9,44 Unit Price incl. VAT

SCR-TFHFL-1/4-20X0.75 CHS ZY3

7512232

$2,09 Unit Price incl. VAT

GUARD ROCK BLK.

5222272067

Not Available

RIVET (50)

7661825

$1,04 Unit Price incl. VAT

ASM. REFLECTOR AMBER [TO 7/11/16]

2670134

$19,94 Unit Price incl. VAT

TRIM FOOTREST

5431484

Not Available

PAD FOOT LH. Substituted by 1040274-117

1040189

$132,29 Unit Price incl. VAT

FOOTPAD RH (ATV) Substituted by 1040275-117

1040275

Not Available

RIVET (MONOBOLT) Substituted by 7661637

7661620

7661637

$2,09 Unit Price incl. VAT

NUT-5/16-18 NYLOK-Y [INTL]

7542324

$1,56 Unit Price incl. VAT

RACK REAR

2670138067

Not Available

CAP BUMPER 4 WHL.(10) Substituted by 5410794

5430823

Not Available

WASHER-.5X.262X.06(16 GA)-Y

7555827

$7,34 Unit Price incl. VAT

PIN COTTER(10)

7661103

Not Available

ROD BRAKE LINKAGE

5224437

$15,42 Unit Price incl. VAT

SPRING-EXHAUST

7042029

$10,49 Unit Price incl. VAT

PEDAL BRAKE

1910054067

Not Available

PIN SPIRAL(10)

7661416

Not Available

PEDAL FOOT

5130715067

Not Available

WASHER THRUST(10)

7558702

$3,14 Unit Price incl. VAT

BUSHING-PEDAL PIVOT

5431107

$16,79 Unit Price incl. VAT

BUMPER FRT BLK (4X4 350) Substituted by 2670148-067

2670119067

Not Available

SCR-HH-5/16-18X1.75 GR5 ZY3

7512329

$7,34 Unit Price incl. VAT

BOLT HEX

7512163

$7,34 Unit Price incl. VAT

WASHER [INTL]

7558301

$2,09 Unit Price incl. VAT

PLUG RUBBER-HOLE .5DIA(10) Substituted by 5411426

5410012

Not Available

GROMMET

5410437

$5,24 Unit Price incl. VAT

Plug Frame

5810467

Not Available

ASM. REFLECTOR RED

2670133

$9,23 Unit Price incl. VAT

WASHER SPRING LOCK

7552801

$3,14 Unit Price incl. VAT

GUARD CLUTCH INNER

5211359067

Not Available

GUARD CLUTCH OUTER

5222860067

Not Available

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
