HYDRAULICS PUMP VALVE HOUSING FOR BRUTUS/HD/HD PTO - D131D9JDJ/1L9JDJ/2M9JDJ FROM 2013

HYDRAULICS MOTOR

HYDRAULICS TILT CYLINDER

HYDRAULICS PUMP VALVE HOUSING

1

SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]

*******

Not Available

2

CAP END

3120667

$692,99 Unit Price incl. VAT

3

ADAPTER

3120675

$325,49 Unit Price incl. VAT

4

PIN

3120621

$2,61 Unit Price incl. VAT

5

BEARING NEEDLE

3120666

$51,23 Unit Price incl. VAT

6

PLUG [INCL. 7]

3120663

Not Available

7

O-RING

3120740

Not Available

8

SPRING

3120627

$10,49 Unit Price incl. VAT

9

VALVE

3120622

$299,24 Unit Price incl. VAT

10

PLUG [INCL. 11]

3120619

$23,09 Unit Price incl. VAT

11

O-RING

3120588

$5,55 Unit Price incl. VAT

12

O-RING

3120628

$11,96 Unit Price incl. VAT

13

O-RING

3120647

$17,84 Unit Price incl. VAT

14

O-RING

3120725

$16,79 Unit Price incl. VAT

15

PLUG [INCL. 16]

3120664

$30,96 Unit Price incl. VAT

16

O-RING

3120629

$6,08 Unit Price incl. VAT

17

SPRING

3120681

Not Available

18

VALVE RELIEF CONE

3120658

Not Available

19

PLUG [INCL. 20]

3120616

$24,98 Unit Price incl. VAT

20

O-RING

3120588

$5,55 Unit Price incl. VAT

21

SCREW

3120679

$11,01 Unit Price incl. VAT

22

O-RING

3120617

$22,04 Unit Price incl. VAT

23

COUPLING [INCL. 24]

3120676

Not Available

24

RING RETAINING

3120671

$18,89 Unit Price incl. VAT

25

KIT SEAL [INCL. 7 13 14 17 21-23 AND FROM HYDRAULICS PUMP MAIN HOUSING PAGE Ref. 7 16 17]

3120661

Not Available

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
