1
Engine displacement
500
2
Year
2002
3
Trim
500 WIDETRAK LX
4
Parts Catalog
CYLINDER
5
Parts Diagram
Parts Catalog
OIL TANK/AIR BOX
by
PISTON CRANKSHAFT
CYLINDER
1
BOLT FLANGE
3085582
$7,34 Unit Price incl. VAT
2
HEAD CYLINDER (Incl. 20)
3085584
$782,24 Unit Price incl. VAT
3
PLUG
3084491
Not Available
4
GASKET ALUMINUM
3084492
$7,34 Unit Price incl. VAT
5
NUT(10)
3080285
Not Available
6
WASHER LOCK (10)
3080530
$6,29 Unit Price incl. VAT
7
GASKET-EXHAUST
3086995
Not Available
8
PIN DOWEL Substituted by 3086838
3080103
$13,64 Unit Price incl. VAT
9
STUD (10)
3085326
Not Available
10
CYLINDER (Incl. 9)
3085583
$832,64 Unit Price incl. VAT
11
NUT FLANGE
3082911
7547013
$3,14 Unit Price incl. VAT
12
GASKET BASE
3084768
$94,49 Unit Price incl. VAT
13
ASM. VALVE CHECK
3086785
7051020
$68,24 Unit Price incl. VAT
14
ASM. BAND ADAPTOR [INCL. 9]
3083166
7082340
$36,74 Unit Price incl. VAT
15
SCREW
3081497
$4,19 Unit Price incl. VAT
16
ADAPTER CARB. (Incl. 17)
3085044
Not Available
17
O-RING
3085619
5418045
$36,74 Unit Price incl. VAT
18
BOLT SOCKET HEAD
3081330
$7,34 Unit Price incl. VAT
19
SWITCH THERMAL IOS
3084284
Not Available
20
PIPE WATER (Water)
3083452
Not Available
21
GASKET 2 HEAD
3085585
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
