1
Engine displacement
500
2
Year
2004
3
Trim
RANGER 2X4,4X4,6X6 - A04RB42AA
4
Parts Catalog
PARKING BRAKE LOCK
5
Parts Diagram
Parts Catalog
WISHBONES
by
REAR BRAKE CALIPERS
PARKING BRAKE LOCK
-
10
10
15
16
10
10
10
19
20
20
21
21
22
23
24
25
10
27
10
10
-
Asm. Parking Brake w/Switch [Incl. 4-10 13 14 17-20 22 23]
1910604
Not Available
1
Cable Brake Parking Main [6x6]
7081018
Not Available
1
Cable Brake Parking Main
7081010
Not Available
2
U-Bolt
5245209
Not Available
3
NUT-HEX-3/8-16 A ZTB NYL
7542451
$2,09 Unit Price incl. VAT
4
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
5
Rod Parking Brake
5133067
$30,75 Unit Price incl. VAT
6
GROMMET
5410437
$5,24 Unit Price incl. VAT
7
NUT-M6X1 HX R.HAND-Y
7546701
$7,34 Unit Price incl. VAT
8
Handle Parking Brake
7081013
$88,19 Unit Price incl. VAT
9
Spring Catch Parking Brake
7042057
Not Available
10
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
11
WASHER FLAT
7558201
$9,44 Unit Price incl. VAT
12
PIN COTTER(10)
7661103
Not Available
13
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
14
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
15
WASHER-.312 X .734 X .065-Z
7558302
$3,14 Unit Price incl. VAT
16
PIN CLIP 14MM
7661140
$2,09 Unit Price incl. VAT
17
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
18
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
19
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
20
BOLT BRAKE LEVER(10)
7512287
Not Available
21
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
22
Cable Brake Parking RH
7081011
Not Available
23
DECAL-WARNING NO PASSENGER
7081012
$188,99 Unit Price incl. VAT
24
SCR-1/4-20X5/8 TAP/R-Y
7517386
$2,09 Unit Price incl. VAT
25
Asm. Equilizer and Pin
2632418
Not Available
26
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
27
Spring Parking Brake
7042056
$109,19 Unit Price incl. VAT
28
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
29
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
