ENGINE, ALTERNATOR AND COMPRESSOR FOR RANGER CREW 1000 EPS FROM 2018

ELECTRICAL, DASH INSTRUMENTS AND CONTROLS

ENGINE, COOLING SYSTEM

ENGINE, ALTERNATOR AND COMPRESSOR

1

PULLEY-FLAT IDLER 70.9MM

3023107

$83,99 Unit Price incl. VAT

2

COMPRESSOR-HVAC

3023108

$755,99 Unit Price incl. VAT

3

ALTNTR 12V 120A [TO 1/17/2018]

4015754

$1 007,99 Unit Price incl. VAT

3

ALTNTR-12V 120A (INCL. 4)

4017099

$1 007,99 Unit Price incl. VAT

4

WASHER IDLER

5140081

$98,98 Unit Price incl. VAT

5

BELT-HVAC DRIVE

5415804

$47,55 Unit Price incl. VAT

6

GASKET-HVAC COMPRESSOR

5415805

$20,99 Unit Price incl. VAT

7

SCR-HXFL-M10X1.5X140 8.8 ZOD

7519041

$19,94 Unit Price incl. VAT

8

ASM COMPRESSOR SUPPORT

3023168

$120,74 Unit Price incl. VAT

9

SCR-HXFL-M10X1.25X25 8.8 Z NY

7518760

$17,84 Unit Price incl. VAT

10

SCR-HXFL-M10X1.5X35 10.9 ZOD D

7519782

$7,34 Unit Price incl. VAT

11

SCR-HXFL-M10X1.5X30 8.8 ZOD

7519764

$4,19 Unit Price incl. VAT

12

NUT-M10X1.25 FLG NYLOC-OLIVE D

7547333

$3,14 Unit Price incl. VAT

13

CLAMP RUBBER-COATED .562(10)

7080573

$13,64 Unit Price incl. VAT

14

BOLT-M8X1.25X25 HXFLG-OLIVE D

7518514

$3,14 Unit Price incl. VAT

15

CLIP-P 7/16X.343 HOLE

7081722

$7,34 Unit Price incl. VAT

16

NUT-M8X1.25 HXFLG NYLON INS

7547317

$5,24 Unit Price incl. VAT

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
