1
Engine displacement
570
2
Year
2014
3
Trim
RANGER 570 EFI - R14RH57AA/AC/AR/6EAZ
4
Parts Catalog
CHASSIS, CAB FRAME
5
Parts Diagram
Parts Catalog
TAILGATE ASM.
by
CHASSIS, FRAME AND FRONT BUMPER
CHASSIS, CAB FRAME
1
2
3
3
3
4
4
4
4
5
6
6
7
7
7
1
2
2
3
3
4
4
5
5
6
6
7
7
1
WELD-CAB FRAME FRONT MATTE BLK
1016686458
$913,49 Unit Price incl. VAT
2
FRAME CAB REAR MATTE BLACK
1016688458
Not Available
3
SCR-3/8 16X1 1/4 HXSOC CS ZY3
7517935
$4,19 Unit Price incl. VAT
4
NUT-HEX-3/8-16 A ZTB NYL
7542451
$2,09 Unit Price incl. VAT
5
SCR-HXFL-M8X1.25X20 8.8 ZY3
7518702
$7,34 Unit Price incl. VAT
6
SCR-M8X1.25X60-HX/FL-Y
7516733
$11,54 Unit Price incl. VAT
7
NUT-M8X1.25 HXFLG NYLON INS
7547317
7548028
$5,24 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
