FRONT SUSPENSION SHOCK
5
Parts Diagram
Parts Catalog
STEERING
by
SEAT
FRONT SUSPENSION SHOCK
1
2
3
4
4
5
5
6
6
1
2
3
4
1
2
1
RETAINER-SPRING STEEL
5251753
$19,94 Unit Price incl. VAT
2
CAM-ADJUSTING SPRING STEEL
5253768
$68,24 Unit Price incl. VAT
3
SHOCK FRONT
7043755
$230,99 Unit Price incl. VAT
4
SPRING MATTE BLACK
7043756458
7045557-458
$204,74 Unit Price incl. VAT
4
SPRING-225# C.SLVR [E87AM BM AB BB]
7043756385
7045557-385
$167,99 Unit Price incl. VAT
5
SCR-HXFL-M10X1.25X60 10.9 ZOD
7519306
$10,49 Unit Price incl. VAT
6
NUT-M10X1.25 FLG NYLOC-OLIVE D
7547333
$3,14 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
