1
Engine displacement
400
2
Year
1994
3
Trim
400L 6X6 - W948740
4
Parts Catalog
COOLING SYSTEM 6X6 400L W948740 (4926802680A010)
5
Parts Diagram
Parts Catalog
FRONT CAB ASSEMBLY 6X6 400L W948740 (4926802680A005)
by
EXHAUST SYSTEM 6X6 400L W948740 (4926802680A011)
COOLING SYSTEM 6X6 400L W948740 (4926802680A010)
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
20
20
20
21
22
23
22
25
26
27
22
29
22
31
32
1
1
2
2
3
4
5
6
7
7
7
7
8
8
9
10
11
12
12
13
14
14
15
15
16
16
17
18
19
20
21
22
23
22
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
26
27
27
22
29
22
22
31
32
1
CLAMP-HOSE (10) Substituted by 7080475
7080233
Not Available
2
HOSE LOWER ENGINE Substituted by 5411173
5410572
$178,49 Unit Price incl. VAT
3
CLAMP-HOSE Substituted by 7080547
7080225
Not Available
4
SWITCH RADIATOR THERMO.
4110099
Not Available
5
DECAL(CPSC) RAD.CAP
7073068
Not Available
6
CAP RADIATOR Substituted by 2511270
2511189
$47,24 Unit Price incl. VAT
7
HOSE ENG UPPER
5410570
$89,24 Unit Price incl. VAT
8
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
9
WASHER [INTL]
7558301
$2,09 Unit Price incl. VAT
10
MOUNT RUBBER
3110032
$15,74 Unit Price incl. VAT
11
SPACER MOUNT
5020572
$16,79 Unit Price incl. VAT
12
WASHER(10)
7552605
$9,44 Unit Price incl. VAT
13
BOLT
7512113
$7,34 Unit Price incl. VAT
14
RADIATOR
1240006
Not Available
15
SCR-RHCAR-1/4-20X0.75 GR5 ZY3
7512193
$4,19 Unit Price incl. VAT
16
COVER RADIATOR W/MESH
5431610
Not Available
17
GUARD LOW.RADIATOR
5222547067
Not Available
18
CLIP-PLASTIC DART NYLON P157
7670078
$6,29 Unit Price incl. VAT
19
O-Ring
5410607
Not Available
20
SHIELD RH RADIATOR
5431189
Not Available
20
SHIELD LH RADIATOR
5431188
Not Available
21
BUSHING-MOUNT LOWER RADIATOR
5410584
$10,49 Unit Price incl. VAT
22
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
23
BLADE FAN Substituted by 5240822
5431262
$92,28 Unit Price incl. VAT
24
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
25
NUT-8-32 HX LK GR A-Y
7541915
Not Available
26
SCREW(10)
7512252
Not Available
27
BRKT COOLING FAN Substituted by 5224741-067
5222559067
Not Available
28
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
29
SPACER FAN BRKT.
5333073
$6,18 Unit Price incl. VAT
30
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
31
WASHER FLAT
7558201
$9,44 Unit Price incl. VAT
32
Screw
7511874
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
