1
Engine displacement
650
2
Year
2023
3
Trim
650 INDY XCR 128
4
Parts Catalog
REAR SUSPENSION
5
Parts Diagram
Parts Catalog
SUSPENSION, IFS SHOCKS MNTG.
by
SUSPENSION, SHOCK MOUNTING, REAR SUSP.
REAR SUSPENSION
1
1
1
2
2
3
3
3
3
3
3
4
4
5
5
6
6
7
7
8
9
9
9
9
9
9
10
10
11
12
13
14
15
16
16
17
18
19
20
21
22
23
23
24
25
25
25
25
25
1
SCR-M10X1.5X35 HXFL ZOD P30
7518957
$6,29 Unit Price incl. VAT
2
NUT-M10X1.25 FLG NYLOC-OLIVE D
7547333
$3,14 Unit Price incl. VAT
3
WASHER
7556545
$6,29 Unit Price incl. VAT
4
SCR-HXFL-M10X1.5X40 10.9ZODP80
7519216
$9,44 Unit Price incl. VAT
5
WASHER
7556153
$3,66 Unit Price incl. VAT
6
SCR-M10X1.5X35 TX/TRUSS ZODP30
7520369
$11,54 Unit Price incl. VAT
7
SCR-TXBH-M10X1.5X45 8.8ZOD P30
7520323
$10,49 Unit Price incl. VAT
8
WASHER-SPRING.406X1.25X.125ZOD
7556490
$9,44 Unit Price incl. VAT
9
BEARING
3514384
3515142
$34,64 Unit Price incl. VAT
9
ASM. WHEEL SPOKE
1590459
$82,94 Unit Price incl. VAT
9
RING RETAINING
7710444
$15,74 Unit Price incl. VAT
10
SPACER IDLER
5432535
$20,99 Unit Price incl. VAT
11
SHAFT IDLER
5136745
$62,99 Unit Price incl. VAT
12
BUSHING
7555918
$3,14 Unit Price incl. VAT
13
SPACER IDLER CENTER
5333283
$27,29 Unit Price incl. VAT
14
BRACE-COUPLING XCR
5143854
$89,24 Unit Price incl. VAT
15
BUMPER-PIVOT ALUM
5142728
$54,59 Unit Price incl. VAT
16
SCR-HXFL-M10X1.25X250 10.9 ZOD
7519327
$36,74 Unit Price incl. VAT
17
SHAFT-CROSS
5139172
$47,24 Unit Price incl. VAT
18
ARM REAR PIVOT ARM BLACK
1543905329
$188,99 Unit Price incl. VAT
19
FITTING-LUBRICATION 1/4-28
7080424
$9,44 Unit Price incl. VAT
20
SHAFT CROSS
5137418
$62,99 Unit Price incl. VAT
21
H-BRACKET ECOAT
1544014329
$173,24 Unit Price incl. VAT
22
SHAFT-H-BRKT CC AL
5140492
$68,24 Unit Price incl. VAT
23
WSHR-M10.5X25X2.4 ZPC
7556559
$6,29 Unit Price incl. VAT
24
SHAFT-LIMITER METRIC HD
5143149
$62,99 Unit Price incl. VAT
25
TRACK-15X128# 1.25 ICE RIP XT TRACK OPTION
5417029
$1 080,44 Unit Price incl. VAT
25
CLIP SLIDE
5251273
$18,89 Unit Price incl. VAT
25
TRACK-15X128# 1.352COBRA 2.52P TRACK OPTION
5416296
$972,29 Unit Price incl. VAT
25
CLIP GUIDE
5251274
$13,64 Unit Price incl. VAT
25
TRACK-15X128# 1.6 COBRA TRACK OPTION
5417768
$1 248,44 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
