1
Engine displacement
900
2
Year
2016
3
Trim
RANGER XP 900 EU
4
Parts Catalog
WIRE HARNESS
5
Parts Diagram
Parts Catalog
DRIVE TRAIN, MAIN GEARCASE MOUNTING
by
ENGINE, BALANCER
WIRE HARNESS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
HARNESS CHASSIS EPS EU [INCL 2-12]
2413326
Not Available
2
LABEL FUSE BOX
7182514
Not Available
3
CLIP-ROUTING
7081496
$9,44 Unit Price incl. VAT
4
GROMMET
5414435
$68,24 Unit Price incl. VAT
5
COVER - DIAGNOSTIC W/ CLIP
4012170
$16,79 Unit Price incl. VAT
6
BREAKER-CIRCUIT 20 AMP
4011372
$83,99 Unit Price incl. VAT
7
RELAY-SPST SERIES 303 SEALED
4011283
4016819
$68,24 Unit Price incl. VAT
8
CLIP-EDGE 1-3MM 6-45MM SERT.
7081808
$10,49 Unit Price incl. VAT
9
FUSE-PARK 20 AMP
2434017
4012811
$15,74 Unit Price incl. VAT
10
FUSE-IGNITION 10 AMP
2434016
$10,49 Unit Price incl. VAT
11
KIT FUSIBLE LINK .8 MM
2202607
$73,49 Unit Price incl. VAT
12
LINK-FUSIBLE 0.5mm sq. X 160mm LONG (GY)
2202147
$125,99 Unit Price incl. VAT
13
HARNESS BOX RANGER EU
2412835
$85,88 Unit Price incl. VAT
14
SCR-HXFL-M6X1.0X25 8.8 RIE
7518533
$2,09 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
