1
Engine displacement
800
2
Year
2019
3
Trim
800 SWITCHBACK PRO-S SC SELECT
4
Parts Catalog
FRONT TORQUE ARM
5
Parts Diagram
Parts Catalog
STEERING, SKI ASM.
by
FRONT TRACK SHOCK (BLACK)
FRONT TORQUE ARM
1
1
2
3
4
5
6
7
8
9
9
10
11
12
13
13
14
1
BUSHING PIVOT
5438875
$20,99 Unit Price incl. VAT
2
ASM. ARM TORQUE FRONT BLACK [INCL. 1]
1543184329
1544186-329
$467,24 Unit Price incl. VAT
3
NUT-M10X1.5 HFN NYLOC ZOD
7547423
$7,34 Unit Price incl. VAT
4
BUSHING
5137360
$7,34 Unit Price incl. VAT
5
SCR-M10X1.5X50 8.8 HX/FL ZOD
7518971
$12,59 Unit Price incl. VAT
6
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
7
NUT-HEX M10X1.5 8 ZOD NYL
7547442
$7,34 Unit Price incl. VAT
8
SCREW M8x30 TR/TX
7518953
$3,14 Unit Price incl. VAT
9
WASHER
7556175
$9,44 Unit Price incl. VAT
10
NUT- M8X1.25 FLG NYLOC-OLIVE D
7547332
$7,34 Unit Price incl. VAT
11
STRAP LIMITER
5414733
$47,24 Unit Price incl. VAT
12
SCREW M10x75 HCS
7519015
$10,49 Unit Price incl. VAT
13
WASHER
7556545
$6,29 Unit Price incl. VAT
14
SHAFT PIVOT
5138648
$26,24 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
