STRUT ASSEMBLY 250 4X4 / W928127 (4922872287B009)
5
Parts Diagram
Parts Catalog
CONTROL ASSEMBLY 250 4x4 / W928127 (4922872287B007)
by
FRONT WHEEL ASSEMBLY 250 4X4 / W928127 (4922872287B010)
STRUT ASSEMBLY 250 4X4 / W928127 (4922872287B009)
1
NUT FLEX LOC(10)
7542507
Not Available
2
WSHR-.500X1.50-12GA-Y
7555749
$2,09 Unit Price incl. VAT
3
SPACER-RUBBER
5810291
$7,34 Unit Price incl. VAT
4
PIVOT BALL TOP Substituted by 5432872
5430806
5432872
$19,94 Unit Price incl. VAT
5
SPACER THREADED (Before 11/2/98)
5130668
$52,49 Unit Price incl. VAT
6
SLEEVE STRUT HUB SEAL
5222193
$120,74 Unit Price incl. VAT
7
BUMPER RUBBER
5410429
Not Available
8
SEAL HUB STRUT
3610028
$57,74 Unit Price incl. VAT
9
HUB STRUT ASM LH (Incl. 6 18 20 23 24)
1843033
Not Available
9
HUB STRUT ASM RH (Incl. 6 18 20 23 24)
1843034
Not Available
10
WASHER-5/16 SPRING LK-MED-Y
7552901
$2,09 Unit Price incl. VAT
11
SCREW CAP(10) [CALIPER MOUNTING]
7512365
$2,09 Unit Price incl. VAT
12
WASHER-.344X.688X.063 FL-Y
7558402
$1,56 Unit Price incl. VAT
13
CALIPER ASM LH BRAKE Substituted by 1910173 (Complete) (#J# Model Only)
1910074
Not Available
13
CALIPER ASM RH BRAKE Substituted by 1910174 (Complete) (#J# Model Only)
1910075
Not Available
14
BRG TAPER.ROLL.CONE
3554506
$54,59 Unit Price incl. VAT
15
SPRING COIL FR.SHOCK
7041238067
Not Available
16
RETAINER SPRING TOP (Before 11/2/98)
5220602
Not Available
17
PIVOT BALL BOTTOM Substituted by 5432871
5430807
5432871
$19,94 Unit Price incl. VAT
18
COIL MAGNETIC
4170003
$120,74 Unit Price incl. VAT
19
CLAMP(10) Substituted by 7080573
7080347
7080573
$13,64 Unit Price incl. VAT
20
RETAINER WIRE STRUT CAST
5810439
Not Available
21
SHAFT ASM DRIVE W/SLEEVE
1380052
Not Available
22
SCR-1/4-20X5/8 FL HX SOC CP-Y
7512284
$2,09 Unit Price incl. VAT
23
BRG TAPER ROLL CUP
3554507
$54,59 Unit Price incl. VAT
24
FITTING LUB W/BALL
7080306
$5,76 Unit Price incl. VAT
25
SCR-HH-5/16-18X2.25 GR5 ZY3
7515339
$9,44 Unit Price incl. VAT
26
NUT FLEX-LOC(10)
7542303
$11,54 Unit Price incl. VAT
28
WASHER-2.06X2.62X.105-Y [BJ/BK/BX/B9]
5211115
$7,34 Unit Price incl. VAT
29
SHOCK FR.STRUT Substituted by 7041451
7041211
Not Available
30
BALL JOINT Substituted by 7080673 (Incl. 32-34)
7080364
7061306
$52,49 Unit Price incl. VAT
31
BRACKET-BALL JOINT
5211121
$62,99 Unit Price incl. VAT
32
BOOT RUBBER
5410548
5412658
$9,44 Unit Price incl. VAT
33
NUT-3/8-24 HX CA GR5-Y
7542438
$3,14 Unit Price incl. VAT
34
PIN COTTER
7661203
$2,09 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
