1
Engine displacement
500
2
Year
1998
3
Trim
SPORTSMAN 500 - W98CH50A
4
Parts Catalog
INLET EXHAUST
5
Parts Diagram
Parts Catalog
CRANKSHAFT AND PISTON
by
CARBURETOR
INLET EXHAUST
1
2
3
4
5
6
6
7
8
8
8
9
9
9
10
11
11
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
1
2
3
4
5
6
6
7
8
8
8
9
9
9
10
11
11
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
1
Plug
3084845
Not Available
2
Gasket Plug
3084920
Not Available
3
SPRING TENSIONER
3084919
Not Available
4
TENSIONER ASM. (Incl. 5-7)
3084918
Not Available
5
Gasket Tensioner
3084922
Not Available
6
Asm. Rocker Arm Intake [Incl. 8 9]
3084910
$230,99 Unit Price incl. VAT
7
Asm. Rocker Arm Exhaust [Incl. 8 9]
3084913
$262,49 Unit Price incl. VAT
8
NUT
3084912
$7,34 Unit Price incl. VAT
9
Screw Adjusting
3084911
$17,84 Unit Price incl. VAT
10
Shaft Rocker
3084909
$99,74 Unit Price incl. VAT
11
Collet Valve
3084908
$9,44 Unit Price incl. VAT
12
RETAINER SPRING Substituted by 3086893
3084907
Not Available
13
Spring Valve
3084906
$52,49 Unit Price incl. VAT
14
CAMSHAFT Substituted by 3086212 (Incl. 17-20)
3084898
$598,49 Unit Price incl. VAT
15
PIN DOWEL Substituted by 3086838
3080103
$13,64 Unit Price incl. VAT
16
Lever Release
3085348
Not Available
17
Spring Return
3085076
Not Available
18
Pin Dowel
3084899
$13,64 Unit Price incl. VAT
19
Sprocket 2
3084914
$141,74 Unit Price incl. VAT
20
BOLT&WASHER ASM.
3081657
$9,44 Unit Price incl. VAT
21
Guide Chain
3084916
Not Available
22
Chain Timing
3084915
$188,99 Unit Price incl. VAT
23
Bolt Pivot
3084924
Not Available
24
Lever
3084917
$173,24 Unit Price incl. VAT
25
Valve Intake
3085349
$125,99 Unit Price incl. VAT
26
VALVE EXHAUST Substituted by 3085412
3084905
$173,24 Unit Price incl. VAT
27
Bolt Flange
3084874
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
