1
Engine displacement
500
2
Year
2002
3
Trim
500 CLASSIC TOURING
4
Parts Catalog
FRONT SUSPENSION
5
Parts Diagram
Parts Catalog
HOOD
by
SKI
FRONT SUSPENSION
1
1
2
3
3
4
4
5
6
6
7
7
8
9
9
10
11
12
13
14
15
16
17
18
19
19
20
21
21
21
22
23
23
24
25
26
27
27
28
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
1
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
2
BRACE FR.BULKHEAD
5242117
Not Available
3
STRAP-SPACER BOTTOM
5211345
$19,94 Unit Price incl. VAT
4
STRAP-SPACER TOP
5211344
$13,64 Unit Price incl. VAT
5
BOLT(10)
7512582
Not Available
6
BOLT(10)
7512684
Not Available
7
SCREW
7515415
$2,09 Unit Price incl. VAT
8
NUT-3/8-24(NYLOK)-Y
7542439
$2,09 Unit Price incl. VAT
9
SHOCK GAS IFS SELECT
7041503
Not Available
10
RETAINER SPRING SLOTTED CAST
5630580
5020618
$36,74 Unit Price incl. VAT
11
SPRING COMP. IFS 100# BLK
7041551067
$115,49 Unit Price incl. VAT
12
RING SPRING PRELOAD ADJ. [1 PER SHOCK]
5431734
$104,99 Unit Price incl. VAT
13
RETAINER SPRING BODY THD. [1 PER SHOCK]
1500063
$83,99 Unit Price incl. VAT
14
BAR SWAY 5/8(X-12)BLK
5224748067
Not Available
15
BUSHING SWAY BAR
5432038
Not Available
16
RIVET (50)
7621477
$2,09 Unit Price incl. VAT
17
ARM-STEERING SLV
5241560244
Not Available
18
BUSHING RADIUS ROD PIVOT
5411099
$20,99 Unit Price incl. VAT
19
SCR-3/8-24X2 HX/CP GR5-Y-SP
7517583
$7,34 Unit Price incl. VAT
20
Washer .105
7555832
$4,19 Unit Price incl. VAT
21
Nut
7542403
Not Available
22
RIVET-3/16-.214-.420
7661130
$2,09 Unit Price incl. VAT
23
WASHER
7555721
$2,09 Unit Price incl. VAT
24
BUSHING
5010310
$19,94 Unit Price incl. VAT
25
PIVOT RUBBER
5410872
$15,74 Unit Price incl. VAT
26
BOLT(10)
7512557
$11,54 Unit Price incl. VAT
27
ASM-TRAILING ARM LH SILVER (Incl. 14 15)
1821081
Not Available
27
ASM-TRAILING ARM RH SILVER (Incl. 14 15)
1821082
Not Available
28
SLIDE SWAYBAR 5/8
5432561
$52,49 Unit Price incl. VAT
29
STOP-STEERING LH SLV
5241569244
Not Available
29
STOP-STEERING RH SLV
5241570244
$5,66 Unit Price incl. VAT
30
BUSHING FLANGE
3573909
$4,19 Unit Price incl. VAT
31
BUSHING
7556509
$3,14 Unit Price incl. VAT
32
BUSHING FLANGED
3574208
$6,29 Unit Price incl. VAT
33
FITTING LUB W/BALL
7080306
$5,76 Unit Price incl. VAT
34
SHAFT SPINDLE TRLG BLK
6230102067
$440,99 Unit Price incl. VAT
35
BUSHING [BEA]
5010158
$27,29 Unit Price incl. VAT
36
FITTING LUBRICATION
7080433
$2,09 Unit Price incl. VAT
37
BUSHING PIVOT RADIUS ROD OUTER
5431486
$6,29 Unit Price incl. VAT
38
BUSHING
5010127
$12,59 Unit Price incl. VAT
39
WELD-RADIUS ROD LOWER SLV
1822383244
Not Available
40
NUT-1/2-20 HX JM-Y
7542711
$4,19 Unit Price incl. VAT
41
ROD END-RADIUS RH LOWER
7061052
$99,74 Unit Price incl. VAT
42
BRKT. RADIUS ROD BOTTOM
5242578
$68,24 Unit Price incl. VAT
43
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
44
NUT FLEX (10)
7542703
Not Available
45
NUT LOCK (10)
7542503
$18,89 Unit Price incl. VAT
46
BUSHING PIVOT
5411095
$27,29 Unit Price incl. VAT
47
ASM-RADIUS ROD UPPER FIXED SLV (Incl. 45 53)
1821084
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
