1
Engine displacement
500
2
Year
2005
3
Trim
SPORTSMAN 6X6 - A05CL50AA
4
Parts Catalog
COOLING SYSTEM
5
Parts Diagram
Parts Catalog
by
ENGINE MOUNTING
COOLING SYSTEM
1
1
2
3
4
5
6
7
8
8
9
9
10
11
11
12
13
14
14
15
16
17
18
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
34
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
CLAMP HOSE WORM GEAR 1.25
7080614
$13,64 Unit Price incl. VAT
2
Cap Pressure
1240044
1240508
$89,24 Unit Price incl. VAT
3
FILLER-REMOTE COOLANT
5433364
$73,49 Unit Price incl. VAT
4
Bracket Filler Coolant
5243505
Not Available
5
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
6
Flexguard
5433948
Not Available
7
Hose Engine Upper
5411811
$110,24 Unit Price incl. VAT
8
Clamp [If built before 11/01/04]
7080827
7080843
$7,34 Unit Price incl. VAT
9
SCR-10-24X1/2 PHTXTRIRD SEMS-Y
7512084
$2,09 Unit Price incl. VAT
10
Hose Neck Filler
5411632
Not Available
11
Clamp Roto Clip
7080826
$9,44 Unit Price incl. VAT
12
Screw
7517659
$7,34 Unit Price incl. VAT
13
Asm. Fan and Motor
2410430
Not Available
14
U-Clip
7670111
Not Available
15
NUTSERT-1/4-20 HEX .165 GRIP
7547069
$7,34 Unit Price incl. VAT
16
MOUNT RUBBER
3110032
$15,74 Unit Price incl. VAT
17
SPACER MOUNT
5020572
$16,79 Unit Price incl. VAT
18
Shroud Fan
5433059
Not Available
19
Radiator
1240178
$1 097,24 Unit Price incl. VAT
20
WASHER SPRING LOCK
7552801
$3,14 Unit Price incl. VAT
21
BOLT(10)
7512240
$7,34 Unit Price incl. VAT
22
WASHER [INTL]
7558301
$2,09 Unit Price incl. VAT
23
O-Ring
5411633
Not Available
23
Valve Plastic Radiator/Cooler Drain
7052296
Not Available
24
BUSHING-MOUNT LOWER RADIATOR
5410584
$10,49 Unit Price incl. VAT
25
Bracket Radiator Lower
5243503067
$230,99 Unit Price incl. VAT
26
SCR-TFHFL-1/4-20X0.75 CHS ZY3
7512232
$2,09 Unit Price incl. VAT
27
Hose Engine Lower
5411694
Not Available
28
Guard Hose
5521511
$11,96 Unit Price incl. VAT
29
CAP-OVER FLOW BOTTLE DRILLED
5430743
$10,49 Unit Price incl. VAT
30
GASKET-OVERFLOW CAP
5810279
$4,19 Unit Price incl. VAT
31
PLUG-CAP 9X(GREEN) FLEX TEMP
5433774
$10,49 Unit Price incl. VAT
32
Tank Surge
5433410
Not Available
33
HOSE [BULK SVC]
84500031525
$136,49 Unit Price incl. VAT
34
FITTING-1/8-27 BARBED 90 DEG
7052065
$13,64 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
