1
Engine displacement
1050
2
Year
1997
3
Trim
SLTX - B974590
4
Parts Catalog
WATER INLET SLTX B974590 AND INTL. SLTX I974590 (4941214121B008)
5
Parts Diagram
Parts Catalog
AIR INTAKE SLTX B974590 AND INTL. SLTX I974590 (4941214121B007)
by
ELECTRICAL BOX SLTX B974590 AND INTL. SLTX I974590 (4941214121B009)
WATER INLET SLTX B974590 AND INTL. SLTX I974590 (4941214121B008)
1
STRAP PANDUIT 4 IN.(10)
7080483
Not Available
2
PITOT LINE 90DEG.FORMED 345CM.
8450070345
Not Available
3
NUT
7547003
Not Available
4
WASHER FLAT NYLON(10)
7555873
Not Available
5
GASKET PILOT
5810879
Not Available
6
WASHER FLAT S.S.(10) (.02)
7555848
Not Available
7
FITTING PILOT MOLDED
5431634
Not Available
8
SCOOP INLET
5131602
$73,07 Unit Price incl. VAT
9
O-RING PUMP HSG/HULL
5410652
Not Available
10
INSERT RIDEPLATE
7010083
$10,70 Unit Price incl. VAT
11
PLATE RIDE LONG ANGLED
5630659
Not Available
12
BOLT SS(10)
7515126
$1,56 Unit Price incl. VAT
13
SCREW (10)
7517267
Not Available
14
BOLT S.S.(10)
7515155
Not Available
15
GRATE INLET CAST BLK.
5630542067
$85,88 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
