Parts Catalog
FRAME
5
Parts Diagram
Parts Catalog
OIL TANK
by
WISHBONES
FRAME
1
1
2
3
3
4
4
4
4
5
6
7
8
8
9
10
10
11
12
12
1
2
3
4
5
6
7
8
9
10
11
12
1
PIN CLEVIS
7661014
$6,81 Unit Price incl. VAT
2
ARM SHIFT MACH 5.69
5131991
$33,59 Unit Price incl. VAT
3
TUBE-PIVOT INTERNAL
5131992
$15,95 Unit Price incl. VAT
4
BUSHING-PEDAL PIVOT
5431107
$16,79 Unit Price incl. VAT
5
SHIFT PIVOT LOW RANGE BLK
1013009067
Not Available
6
SHIFT PIVOT HIGH RNGE BLK
1013008067
Not Available
7
SCREW
7517589
$5,24 Unit Price incl. VAT
8
SCR-1/4-20X5/8 TAP/R-Y
7517386
$2,09 Unit Price incl. VAT
9
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
10
PIN COTTER(10)
7661103
Not Available
11
ARM-SHIFT MACH 11.00
5131988
Not Available
12
PIN CLEVIS
7661013
$10,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
