1
Engine displacement
325
2
Year
2001
3
Trim
325 MAGNUM 2X4 HDS - A01CB32FC
4
Parts Catalog
DRIVEN CLUTCH
5
Parts Diagram
Parts Catalog
DRIVE CLUTCH
by
CLUTCH COVER
DRIVEN CLUTCH
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
BUSHING-.906 X 1 3/8 X 16 GA-Y
7556120
$2,09 Unit Price incl. VAT
2
BELT DRIVE ATV CLOSE TOL(5)
3211077
$107,93 Unit Price incl. VAT
3
Asm. Driven Clutch [Incl. 7-17][2x4]
1321874
$923,99 Unit Price incl. VAT
4
WASHER DOMED
5220646
$4,19 Unit Price incl. VAT
5
WASHER-5/16 SPRING LK-MED-Y
7552901
$2,09 Unit Price incl. VAT
6
SCR-HH-5/16-18X3.75 GR5 ZY3
7515382
$4,19 Unit Price incl. VAT
7
Washer .020
7555898
$2,09 Unit Price incl. VAT
8
Washer .025
7556076
$9,44 Unit Price incl. VAT
9
Washer .030
7556804
$1,56 Unit Price incl. VAT
10
Bearing Moveable (1/2 inch)
3576504
$41,99 Unit Price incl. VAT
11
Bearing Moveable 1 Inch
3576511
$52,49 Unit Price incl. VAT
12
SPRING-CLTCH CHRM SLCN BLK DRI
7041782
$115,49 Unit Price incl. VAT
13
RAMP STA COMP (MACH)
5132344
$146,99 Unit Price incl. VAT
14
SPACER-1.350X1.750X.020-YW/TAB
5244116
$13,64 Unit Price incl. VAT
15
Ring Retaining
7710448
$5,76 Unit Price incl. VAT
16
BOLT(10)
7511854
$2,09 Unit Price incl. VAT
17
BUTTON RAMP
5430766
5450873
$11,54 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
