1
Engine displacement
500
2
Year
2002
3
Trim
ATV PRO 500 4X4 PPS - C02CD50AC
4
Parts Catalog
CONTROLS
5
Parts Diagram
Parts Catalog
FRONT STRUT
by
REAR BRAKE
CONTROLS
-
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
17
18
18
19
20
21
22
23
1
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
18
18
19
20
21
21
22
23
-
Asm. Master Cylinder
2010196
2010238
$456,74 Unit Price incl. VAT
1
Boot Brake Line Rubber
5411297
$3,35 Unit Price incl. VAT
2
SEAL
5410988
$9,44 Unit Price incl. VAT
3
SWITCH-BRK 1/8#-27 NPTF SEALED [BRAKE LIGHTS]
4110164
2890637
$325,49 Unit Price incl. VAT
4
CLIP-RETAINING DUAL .250# LINE
7670126
$9,44 Unit Price incl. VAT
5
SCR-#10-24X3/4 PN/TR RD-TORX-Y (taillight) [S57C1 C9]
7512018
$6,29 Unit Price incl. VAT
6
SCR-1/4-20X5/8 TAP/R-Y
7517386
$2,09 Unit Price incl. VAT
7
CLAMP-HOSE .625 DIA VNL COATED
7080880
$10,49 Unit Price incl. VAT
8
Screw
7517899
$2,09 Unit Price incl. VAT
9
Kit Master Cylinder Cap [Incl. Cap Screws Sight Gasket]
2201834
2202725
$99,74 Unit Price incl. VAT
10
Kit Master Cylinder Park Brake Lever [Incl. Lever Spring]
2201836
$83,99 Unit Price incl. VAT
11
Kit Master Cylinder Clamp [Incl. Clamp Screws]
2201833
$89,24 Unit Price incl. VAT
12
Kit Master Cylinder Lever [Incl. Pin Lever Clip]
2201835
$115,49 Unit Price incl. VAT
13
Line Brake
1910565
Not Available
14
RIVET-POP3/16(.251-.375)AL-B
7621462
$2,09 Unit Price incl. VAT
15
CLAMP-NYLON CABLE 1/4#
7080539
$9,44 Unit Price incl. VAT
16
Conduit
836003134
Not Available
17
Line w/Fittings Brake Front LH
1910474
$167,99 Unit Price incl. VAT
18
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
19
SCR-#10-24X1/2PH/TORX-TRIRD-Y
7512024
$9,44 Unit Price incl. VAT
20
Line Brake Stainless Steel Front RH
1910475
$167,99 Unit Price incl. VAT
21
FITTING-CROSS ATV BRAKE
7052292
$73,49 Unit Price incl. VAT
22
Line Brake Stainless Steel Pod
1910470
$167,99 Unit Price incl. VAT
23
BOLT-BANJO 10MMX1.00-6G
1910499
$10,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
