CRANKCASE (4910931093020A)

CYLINDER (4910931093021A) FOR POLARIS OTHERS 1986

DRIVE CLUTCH (4910931093008A)

Item numbers

CYL. #1 (INCL. 3-4)

3083438

Not available

CYL. #2 (INCL. 34)

3083440

Not available

STUD

3080283

Not available

STUD

3080016

Not available

GASKET-CYL

3083081

Not available

NUT SUBSTITUTED BY 3082911

3080047

Not available

WASHER, SPRING(10)

3080281

Not available

WASHER(10)

3080356

Not available

HEAD CYL.

3083709

Not available

GASKET HEAD

3080250

Not available

NUT(10)

3080119

Not available

NUT SUBSTITUTED BY 3083541

3082632

Not available

LOCK WASHER

3080530

Not available

WASHER(10)

3080142

Not available

GASKET COMPL. (EXHAUST) SUBSTITUTED BY 3083770

3082068

Not available

NUT(10)

3080285

Not available

SPARK PLUG

3070165

Not available

MANIFOLD SUBSTITUTED BY 3083223

3083285

Not available

ADAPTER [NO LONGER AVAILABLE]

3082623

Not available

BAND-CARB MTG. (INCL. 21)

3082257

Not available

PAN HEAD SCREW

3081497

Not available

SOCKET HEAD BOLT

3081330

Not available

NUT

3081086

Not available

INSULATOR

3083176

Not available

GASKET-INTAKE SUBSTITUTED BY 3084027

3083099

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CYLINDER (4910931093021A) of your Polaris NOR LONGTRAK W/REVERSE - N861549 of 1986. Let us know if you have any questions.
