CRANKCASE

CYLINDER FOR POLARIS 500 XC SP 2002

DECALS

Item numbers
CYLINDER - S02NP5CSA/SB (4970697069C07) Polaris SNOWMOBILES 500 2002 500 XC SP 500 XC SP
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
1
SUBSTITUTED BY 4010398

4010614  

Not available
2
SCREW, 8 MM X 1.25 MM X 55 MM

7517533  

Not available
3
SCREW, M6X1.0 X 13, SL/HX/FL-Z

7517679  

Not available
4
FLAT WASHER

7555998  

Not available
5
COVER THERMOSTAT

5630992  

Not available
6
O-RING LIP SEAL

5411521  

Not available
7
COVER-HEAD 70.5 500 BLK E-COAT

5631198329  

Not available
8
O-RING

5411411  

Not available
9
SEAL

5411465  

Not available
10
HEAD CYLINDER

3021276  

Not available
11
O-RING

5411199  

Not available
12
O-RING

5411359  

Not available
13
NUT

7547013  

Not available
14
SUBSTITUTED BY 5813934

5812350  

Not available
15
BASE EXHAUST VALVE

1202216  

Not available
16
SUBSTITUTED BY 5135163

5132950  

Not available
17
SUBSTITUTED BY 5631687

5631152  

Not available
18
SUBSTITUTED BY 1202640

5434175  

Not available
19
SCREW

7516820  

Not available
20
SCR-M6X1.0X50.0 HX/FL-YD (10)

7517932  

Not available
21
SPRING-COMP, GEN3.5EV PRPL/WHT

704178607  

Not available
22
SUBSTITUTED BY 5414495

5412056  

Not available
23
SUBSTITUTED BY 5135159

1201959  

Not available
24
SUBSTITUTED BY 3021334

3021256  

Not available
25
SUBSTITUTED BY 5812494

5811916  

Not available
26
THERMOSTAT

7052267  

Not available
27
SCREW

7516818  

Not available
28
SCREW M6 X 1.0, L-20MM

7516822  

Not available
29
SUBSTITUTED BY 7052312

7052221  

Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CYLINDER - S02NP5CSA/SB (4970697069C07) of your Polaris 500 XC SP of 2002. Let us know if you have any questions.
