Displacement

Year

Finish line

Parts catalogue

Parts diagram

DRIVE CLUTCH

DRIVE TRAIN FOR POLARIS 500 XC SP 2002

DRIVEN CLUTCH

Item numbers
DRIVE TRAIN - S02NP5CSA/SB (4970697069B14) Polaris SNOWMOBILES 500 2002 500 XC SP 500 XC SP
1
2
3
4
5
6
7
8
9
9
10
11
11
11
11
12
13
13
14
15
16
17
18
19
20
20
21
21
22
22
23
23
24
25
26
27
28
29
30
1
BOLT

7515369  

Not available
2
WASHER, FLAT

7555701  

Not available
3
WASHER, FLAT(10)

7555734  

Not available
4
SPACER INPUT SHAFT

5020291  

Not available
5
ASM. DRIVEN CLUTCH R11 (SEE DRIVEN CLUTCH PG. C2 REF. 9)

 

Contact
6
DRIVE BELT

3211080  

Not available
7
WASHER

7555864  

Not available
8
BUSHING

7556509  

Not available
9
NYLOK NUT

7542324  

Not available
10
FLAT WASHER

7558402  

Not available
11
FLANGE RD, RELUBE W/ZERK

5241359  

Not available
11
FITTING, LUB/VEN

7080561  

Not available
12
JACKSHAFT GASKET, BLACK

5811095  

Not available
13
BEARING

3514525  

Not available
14
FLANGETTE

5222751  

Not available
15
CARRIAGE BOLT

7512377  

Not available
16
KEY-1/4X3/16X2.75

7721128  

Not available
17
SUBSTITUTED BY 1332283

1332220  

Not available
18
RING, RETAINING

7710422  

Not available
19
DISC BRAKE

1910403  

Not available
20
BOLT, CARRIAGE

7515428  

Not available
21
SLEEVE SEAL

5020588  

Not available
22
O-RING

5410613  

Not available
23
NUT, FLANGE

7542423  

Not available
24
ASM. DRIVE SHAFT (INCL. 25 26)

1590313  

Not available
25
FLANGETTE W/ SCREWS ASSEMBLY

1012945  

Not available
26
SPEEDO METAL BUSHING

3280019  

Not available
27
OFFSET FLANGETTE WITH HOLE

5243529  

Not available
28
SPEEDOMETER SQUARE KEY

3280017  

Not available
29
GASKET DRIVE ADAPTOR

5830012  

Not available
30
SUBSTITUTED BY 3280540

3280116  

Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the DRIVE TRAIN - S02NP5CSA/SB (4970697069B14) of your Polaris 500 XC SP of 2002. Let us know if you have any questions.
