RAIL MOUNTING (SUSPENSION)

REAR TORQUE ARM FOR POLARIS 500 XC SP 2001

RECOIL STARTER

Item numbers

WELD-REAR TORQUE ARM, RED

1541561293

Not available

NYLOCK NUT

7542439

Not available

SUBSTITUTED BY 7515540

7512410

Not available

ARM SHAFT

5333758

Not available

BUSHING

3514331

Not available

SCREW

7515415

Not available

FLAT WASHER

7555806

Not available

WASHER, FLAT(10)

7555893

Not available

SPRING LOCK WASHER

7552603

Not available

SCREW

7517435

Not available

ARM ASSEMBLY

1541461

Not available

SPACER WHEEL

5132388

Not available

WHEEL ASSEMBLY

1590278

Not available

SUBSTITUTED BY 7555871

7555787

Not available

TORSION SPRING SLEEVE

5431923

Not available

ROLLER, SPRING, ADJ, SQUARE

5432983

Not available

PUSH ON CLIP

7080394

Not available

SUBSTITUTED BY 7041629-329

7041629067

Not available

SUBSTITUTED BY 7041630-329

7041630067

Not available

TORSION SPRING .405 77 LEFT SID

7041940067

Not available

TORSION SPRING .405 77 RIGHT SI

7041941067

Not available

SUBSTITUTED BY 7041942-329

7041942067

Not available

SUBSTITUTED BY 7041943-329

7041943067

Not available

SCREW

7517232

Not available

SHAFT .740X.390X7.055 6066

5333873

Not available

BOLT

7515514

Not available

WAVE SPRING WASHER

7555795

Not available

BUSHING, .378 X .616 X 1.12

5132391

Not available

ROD SHOCK

1541479067

Not available

SCREW-3/8-24X3.75-HX/P-80-GR8Y

7517851

Not available

BUSHING NUT, .616 X 1.12 X .875

5132390

Not available

SLEEVE, .385 X .560 X 1.30

5333907

Not available

LUBRICATION FITTING

7080424

Not available

SPACER .397X.562X1.250

5333904

Not available

SHOCK R/T FOX PPS

7041846

Not available

BUSHING

5010422

Not available
