Displacement

Year

Finish line

Parts catalogue

Parts diagram

DRIVE TRAIN, MAIN GEARCASE

DRIVE TRAIN, MAIN GEARCASE INTERNALS FOR POLARIS RANGER 900 DIESEL 2014

DRIVE TRAIN, MAIN GEARCASE SHIFT FORKS

Item numbers
DRIVE TRAIN, MAIN GEARCASE INTERNALS - R14TH90DG (49RGRTRANSINTL11DCREW) Polaris RANGER 900 2014 RANGER 900 DIESEL RANGER 900 DIESEL - R14TH90DG
1
2
3
3
4
5
6
7
8
8
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
1
DIESEL MAIN GEARCASE ASSEMBLY

1332980  

Unit Price

2
ASM-PRIM.SHAFT, 47 T.(411619/0)

2204333  

Unit Price

3
BALL BEARING

3234657  

Unit Price

4
BALL BEARING

3233265  

Unit Price

5
SHIM KIT

2204268  

Unit Price

6
INTERNAL RETAINING RING

3234741  

Unit Price

7
TRIPLE LIP SEAL

3234769  

Unit Price

8
BEARING

3233019  

Unit Price

9
SUB ASSSEMBLY, BEARING COVER

3235198  

Unit Price

10
SCREW, TORX PAN HD M6 X 1 X 16

3234309  

Unit Price

11
RETAINING RING

3233364  

Unit Price

12
SHIM KIT

2204264  

Contact
13
CUP

3234696  

Unit Price

14
SPRING COMPRESSION

3234999  

Contact
15
WASHER

3234648  

Unit Price

16
SUBSTITUTED BY 9999999

3234705  

Unit Price

17
SPACER COMPENSATOR THRUST

3234697  

Contact
18
FLANGED BEARING

3234684  

Unit Price

19
COMPENSATOR SHAFT

3234721  

Unit Price

20
COLLAR

3234758  

Unit Price

21
BEARING

3233020  

Unit Price

22
THRUST WASHER, 1.300 X .995 X .

3234248  

Unit Price

23
DOG-ENGAGEMENT GTO HIGH

3235190  

Unit Price

24
GEAR-COMPEN., 54 TOOTH(285793)

2204330  

Unit Price

25
EXTERNAL RETAINING RING

3234641  

Unit Price

26
WASHER, THRUST

3234757  

Unit Price

27
HELICAL GEAR, 42T

3235133  

Unit Price

28
NEEDLE BEARING

3234759  

Unit Price

29
INPUT SHAFT, 25 TOOTH

3234761  

Unit Price

30
SILENT CHAIN

3234737  

Unit Price

31
BALL BEARING

3234652  

Unit Price

32
BEARING, BALL, 17 X 40 X 12

3234274  

Unit Price

33
EXTERNAL RETAINING RING

3234318  

Unit Price

34
SHIM

3234644  

Unit Price

35
BEARING, NEEDLE

3234655  

Unit Price

36
SPROCKET, 48 TOOTH

3234707  

Unit Price

37
DOG-ENGAGEMENT, GTO, REV/LOW

3235341  

Unit Price

38
SPRING, WAVE

3234688  

Unit Price

39
DOG-ENGAGEMENT, LOW

3235385  

Unit Price

40
RING, RETAINING BASIC, EXTERNA

3234327  

Unit Price

41
WASHER, THRUST

3234646  

Unit Price

42
NEEDLE BEARING

3234656  

Unit Price

43
GEAR, 67T

3234706  

Unit Price

44
REVERSE SHAFT, 53 TOOTH

3234774  

Unit Price

45
SPROCKET, 19 TOOTH

2204331  

Unit Price

46
SHIM

3234643  

Unit Price

47
SILENT CHAIN, 0.75 X .375 P X 6

3235245  

Unit Price

48
BALL BEARING

3234651  

Unit Price

49
OUTPUT ASSEMBLY, FRONT

3234723  

Unit Price

50
RING-RETAINING

3233699  

Unit Price

51
SPROCKET, 47 TOOTH

2204332  

Unit Price

52
OUTPUT SHAFT

2204329  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Polaris, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
