1
Engine displacement
500
2
Year
1992
3
Trim
SWE 500 SP - S920674
4
Parts Catalog
CYLINDER 500 SP/500 SKS (4921262126040A)
5
Parts Diagram
Parts Catalog
CRANKCASE 500 SP/500 SKS (4921262126039A)
by
PISTON AND CRANKSHAFT 500 SP/500 SKS (4921262126041A)
CYLINDER 500 SP/500 SKS (4921262126040A)
1
CYLINDER CPL. (Incl. 2 3)
3084330
$807,44 Unit Price incl. VAT
2
STUD
3083360
Not Available
3
STUD (10)
3080016
$9,23 Unit Price incl. VAT
4
GASKET BASE Substituted by 3084768
3083959
$94,49 Unit Price incl. VAT
5
NUT FLANGE
3082911
7547013
$3,14 Unit Price incl. VAT
6
NUT(10)
3080285
Not Available
7
HEAD CYL. CPL. (Incl. 8)
3084331
$423,14 Unit Price incl. VAT
8
PIPE WATER (Water)
3083452
Not Available
9
GASKET HEAD
3084332
Not Available
10
NUT-FLANGE(10)
3082910
Not Available
11
WASHER LOCK (10)
3080530
$6,29 Unit Price incl. VAT
12
PLUG Substituted by 3084491
3083044
Not Available
13
GASKET-ALUM Substituted by 3084492
3082719
$7,34 Unit Price incl. VAT
14
SENSOR WATER TEMP. Substituted by 3086138
3084333
Not Available
15
NECK FILLER
3083398
Not Available
16
GASKET FILLER NECK
3083340
Not Available
17
BOLT&WASHER ASM.
3083361
Not Available
18
ADAPTER CPL LH
3084334
Not Available
19
BOLT SOCKET HEAD
3081330
$7,34 Unit Price incl. VAT
20
BAND ASM. (Incl. Bolt)
3084045
$47,24 Unit Price incl. VAT
21
SCREW
3081497
$4,19 Unit Price incl. VAT
22
GASKET EXHAUST
3083770
Not Available
23
ADAPTER CPL. RH
3084335
Not Available
24
O-RING
3084229
Not Available
25
PIPE HEAD (Head)
3084390
Not Available
26
HOSE 1 WATER
3084337
Not Available
27
HOSE 2 WATER
3084338
Not Available
28
CLAMP
3084051
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
