1
Engine displacement
600
2
Year
2004
3
Trim
A04CH59AK SPORTSMAN 600 - A04CH59AK/AL/AN/AQ/AW
4
Parts Catalog
INLET EXHAUST
5
Parts Diagram
Parts Catalog
CYLINDER AND CYLINDER HEAD
by
FRONT STRUT
INLET EXHAUST
1
2
3
3
4
5
6
6
7
8
9
10
10
11
11
11
11
12
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
ASM. ARM ROCKER
1202169
$204,74 Unit Price incl. VAT
2
Pushrod
5132402
5138254
$99,74 Unit Price incl. VAT
3
Kit Camshaft [Incl. 7]
2202363
Not Available
3
Kit Camshaft [Incl. 10][If built after 10/02/03]
2202693
Not Available
4
PLATE THRUST
5244286
$99,74 Unit Price incl. VAT
5
SCREW-M6X12 TORX DR FH
7517598
$19,94 Unit Price incl. VAT
6
Kit Gear Set
2202145
Not Available
7
Spring Compression
7041999
Not Available
8
WASHER SPRING
7556183
$17,84 Unit Price incl. VAT
9
SCREW
7517865
$20,99 Unit Price incl. VAT
10
Lifter Valve
5134152
5137206
$68,24 Unit Price incl. VAT
10
Lifter Valve
5131415
5137206
$68,24 Unit Price incl. VAT
11
Valve Exhaust
5133363
Not Available
11
Valve Exhaust
5133141
Not Available
12
Valve Intake
5131417
$99,95 Unit Price incl. VAT
12
Valve Intake
5132696
5137265
$73,49 Unit Price incl. VAT
13
Seal Valve Guide
5411895
$15,74 Unit Price incl. VAT
14
Spring Valve
7041565
Not Available
15
Retainer Spring
5131413
$41,99 Unit Price incl. VAT
16
RETAINER LOCK
5910042
$10,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
