1
Engine displacement
800
2
Year
2020
3
Trim
800 AXYS SKS 155
4
Parts Catalog
IFS SHOCK W/RESERVOIR
5
Parts Diagram
Parts Catalog
SUSPENSION, RAIL MOUNTING
by
FRONT TORQUE ARM
IFS SHOCK W/RESERVOIR
-
24
25
26
26
27
27
28
29
30
31
31
32
33
34
35
36
37
38
38
39
40
41
42
43
-
SHOCK WALKER EVANS IFS W/RES
7044302
$1 217,99 Unit Price incl. VAT
1
O-RING 2-125
1800027
$3,66 Unit Price incl. VAT
2
ASM. SEAL HEAD
1800403
$220,49 Unit Price incl. VAT
3
RETAINER SPRING
1800046
$68,24 Unit Price incl. VAT
4
SLEEVE
1800405
$62,99 Unit Price incl. VAT
5
BUSHING
1800406
$9,44 Unit Price incl. VAT
6
BAND WEAR
1800297
$62,99 Unit Price incl. VAT
7
NUT CRIMP
1800031
$7,34 Unit Price incl. VAT
8
O-RING BODY LOOP
1800030
$3,66 Unit Price incl. VAT
9
RING SPRING RETAINING
1800658
$89,24 Unit Price incl. VAT
10
BODY IFS 8.495L BLK
1800653
$178,49 Unit Price incl. VAT
11
SHAFT IFS 8.670L .50DIA.
1800732
$230,99 Unit Price incl. VAT
12
BEARING END
1800040
$152,24 Unit Price incl. VAT
13
SNAP RING END BEARING
1800041
$15,74 Unit Price incl. VAT
14
BUMPER
1800462
$68,24 Unit Price incl. VAT
15
SEAL WIPER
1800295
$26,24 Unit Price incl. VAT
16
SEAL U-CUP
1800294
$47,24 Unit Price incl. VAT
17
O-RING
1800095
$2,09 Unit Price incl. VAT
18
BUSHING SHAFT
1800292
$20,99 Unit Price incl. VAT
19
LOOP SHAFT
1800540
$257,24 Unit Price incl. VAT
20
LOOP BODY PB 2#
1800424
$661,49 Unit Price incl. VAT
21
STUD CLICKER
1800352
$57,74 Unit Price incl. VAT
22
KNOB CLICKER BLACK
1800418
$173,24 Unit Price incl. VAT
23
BODY RESERVOIR
1800419
$173,24 Unit Price incl. VAT
24
PISTON RESERVOIR
1800355
$152,24 Unit Price incl. VAT
25
BAND PISTON
1800185
$83,99 Unit Price incl. VAT
26
O-RING
1800184
$10,49 Unit Price incl. VAT
27
O-RING BLEED SCREW
1800210
$3,14 Unit Price incl. VAT
28
SCREW BLEED
1800043
$12,59 Unit Price incl. VAT
29
CAP END RESERVOIR BLACK
1800420
$68,24 Unit Price incl. VAT
30
VALVE NEEDLE
1800329
$62,99 Unit Price incl. VAT
31
O-RING 2-012
1800501
$13,64 Unit Price incl. VAT
32
SCREW BUTTON HEAD
1800109
$6,29 Unit Price incl. VAT
33
PISTON CONVEX
1800001
$246,74 Unit Price incl. VAT
34
SNAP RING 1.75 ID
1800159
$10,49 Unit Price incl. VAT
35
SCREW BTN HD
1800357
$6,29 Unit Price incl. VAT
36
PISTON CLICKER
1800353
$173,24 Unit Price incl. VAT
37
BOLT CLICKER
1800354
$23,09 Unit Price incl. VAT
38
BALL D-TENT
1800127
$12,59 Unit Price incl. VAT
39
RING SNAP CLICKER
1800359
$6,29 Unit Price incl. VAT
40
O-RING CLICKER HOUSING
1800358
$2,09 Unit Price incl. VAT
41
SPRING-D-TENT
1800128
$20,99 Unit Price incl. VAT
42
WASHER
1800050
$7,34 Unit Price incl. VAT
43
SPRING COMPRESSION 100# MBLK
7043460458
$141,74 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
