1
Engine displacement
400
2
Year
1994
3
Trim
400l-2x4-w947540
4
Parts Catalog
ELECTRICAL/TAILLIGHT ASSEMBLY 2X4 400L W947540 (4926752675C005)
5
Parts Diagram
Parts Catalog
GEARCASE ASSEMBLY 2X4 400L W947540 (4926752675C003)
by
TOOL KIT ASSEMBLY 2X4 400L W947540 (4926752675C006)
ELECTRICAL/TAILLIGHT ASSEMBLY 2X4 400L W947540 (4926752675C005)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
1
HARNESS MAIN WIRE(400-4X4)
2460476
Not Available
2
ISOLATOR TAILLIGHT
5211391067
$17,21 Unit Price incl. VAT
3
RIVET(50)
7621470
Not Available
4
WASHER(10) Substituted by 7558301
7555776
7558301
$2,09 Unit Price incl. VAT
5
ASM. TAILLIGHT [INCL. LENS AND SCREW]
2432034
$104,99 Unit Price incl. VAT
6
LENS-TAILLIGHT
4032046
$62,99 Unit Price incl. VAT
7
SCREW-TAILLIGHT
4032029
$9,44 Unit Price incl. VAT
8
BULB TAILLIGHT
4030043
$12,59 Unit Price incl. VAT
9
GASKET TAILLIGHT
4032045
$7,34 Unit Price incl. VAT
10
Backing Taillight/Brakelight
4032064
$152,24 Unit Price incl. VAT
11
SPEED NUT-WASHER HEAD-1/4
7670054
$2,09 Unit Price incl. VAT
12
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
13
CKT.BREAKER 20 AMP.
2434012
Not Available
14
SCR-#10-24-5/8-PN/TORX-M
7512027
$2,09 Unit Price incl. VAT
15
NUT-NYLOC 10-24 Y
7541925
$1,56 Unit Price incl. VAT
16
CABLE SOLENOID/STARTER
4010064
Not Available
17
Cable Battery/Solenoid
4010094
Not Available
18
WASHER-.197X.50 INT/EXT LK-Y
7571602
$9,44 Unit Price incl. VAT
19
DECAL BATTERY [No Longer Available]
7072606
Not Available
20
Cover Battery
5431769
$29,39 Unit Price incl. VAT
21
BOLT BATT KIT(SHORT) (Short) (Not Shown)
2200361
Not Available
22
Cable Battery/Engine
4010095
Not Available
23
Hook Strap Battery
7010032
$3,14 Unit Price incl. VAT
24
STRAP BATTERY HOLDDOWN
5410424
5418182
$9,44 Unit Price incl. VAT
25
HOSE-POLY CLEAR 3/16 OD 1/8 ID
8360009600
$83,99 Unit Price incl. VAT
26
PAD-BATTERY NOT SHOWN
5810290
5810290-CO
$13,64 Unit Price incl. VAT
27
BATTERY 14 AMP [FROM 8/17/2020]
4140006
$136,49 Unit Price incl. VAT
28
RIVET (50)
7621336
$3,14 Unit Price incl. VAT
29
CLAMP BLK 5/16 PLASTIC(10)
7080524
Not Available
30
Plug Power
2410022
Not Available
31
PIGTAIL POWER
2460442
$19,83 Unit Price incl. VAT
32
BOLT
7512007
$7,34 Unit Price incl. VAT
33
RIVET POP(50)
7621322
Not Available
34
BOARD TERMINAL
4040022
Not Available
35
SHIELD TERM.BOARD
5431152
Not Available
36
Sink Heat
5131036
Not Available
37
RECTIFIER SWITCHING
4060113
Not Available
38
HARNESS JUMPER RECTIFIER
2460485
Not Available
39
SCR-#10-24X3/4 PN/TR RD-TORX-Y (taillight) [S57C1 C9]
7512018
$6,29 Unit Price incl. VAT
40
BRKT CDI(ATV 400)
5240428
Not Available
41
LIMITER RPM 350HZ. Substituted by 4060203
4060112
Not Available
42
HEAT SINK
5210650
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
