1
Engine displacement
800
2
Year
2013
3
Trim
RANGER 800 EFI - R13TH76/7E
4
Parts Catalog
DECALS
5
Parts Diagram
Parts Catalog
BED BOX MOUNTING
by
HOOD AND FRONT FASCIA
DECALS
1
2
3
3
3
3
3
3
3
3
3
3
4
4
5
6
6
6
6
6
6
7
7
8
9
10
11
12
13
14
15
15
15
15
15
15
15
15
16
16
16
16
17
18
18
19
20
1
Decal Warning Passenger/Tire Pressure [Built 2/15/11 and After]
7177689
Not Available
2
PLATE HWSR WITHOUT HOLES [ALL 900 XP MODELS]
5256509
$68,24 Unit Price incl. VAT
3
DECAL BOX #RANGER# SOLAR RED RH [6AR][6ARC]
7179132
Not Available
3
DECAL BOX #RANGER# SUNSET RED LH [6AZ][6AZC][EAZ][EAZC]
7179125
Not Available
3
DECAL BOX #RANGER# SOLAR RED LH [6AR][6ARC]
7179131
Not Available
3
DECAL BOX #RANGER# WHITE LH [6AK][EAK][AKC][EAKC]
7179123
Not Available
3
DECAL BOX #RANGER# SAGE BRUSH GREEN LH [6AG][EAG][6AGC][EAGC]
7179121
Not Available
3
DECAL BOX #RANGER# WHITE RH [6AK][EAK][AKC][EAKC]
7179124
Not Available
3
DECAL BOX #RANGER# POLARIS PURSUIT CAMO RH [6AH][6AHC]
7179130
Not Available
3
DECAL BOX #RANGER# SUNSET RED RH [6AZ][6AZC][EAZ][EAZC]
7179126
Not Available
3
DECAL BOX #RANGER# POLARIS PURSUIT CAMO LH [6AH][6AHC]
7179129
Not Available
3
DECAL BOX #RANGER# SAGE BRUSH GREEN RH [6AG][EAG][6AGC][EAGC]
7179122
Not Available
4
Decal #POLARIS# Tailgate Gold [AH][AL][AS]
7175623
Not Available
4
DECAL #POLARIS# TAILGATE WHITE
7175576
$23,09 Unit Price incl. VAT
5
DECAL REFLECTOR RED
7175628
$23,09 Unit Price incl. VAT
6
Decal #800 EFI# Hood Side White LH [6AK][EAK][EAKC][6AKC]
7178016
Not Available
6
Decal #800 EFI# Hood Side White RH [6AK][EAK][EAKC][6AKC]
7178017
Not Available
6
Decal #800 EFI# Hood Gold RH [AH]
7176179
Not Available
6
DECAL 800 EFI HOOD RH
7176177
$20,99 Unit Price incl. VAT
6
Decal #800 EFI# Hood Gold LH [AH]
7176178
Not Available
6
DECAL 800 EFI HOOD LH
7176176
$20,99 Unit Price incl. VAT
7
Decal Dash Side Stripe White LH [6AK][EAK][EAKC][6AKC]
7178012
Not Available
7
Decal Dash Side Stripe White RH [6AK][EAK][EAKC][6AKC]
7178013
Not Available
8
Decal Warning Discretionary
7177615
Not Available
9
LOGO-POLARIS STAR
7078465
$23,09 Unit Price incl. VAT
10
DECAL #APPLY BRAKE TO START#
7170739
Not Available
11
DECAL CAUTION #SHIFT AT IDLE#
7172674
Not Available
12
Decal Hitch 2000 LBS Maximum
7176005
$15,74 Unit Price incl. VAT
13
DECAL PARK BRAKE
7174926
Not Available
14
DECAL AGE WARNING 16
7175566
Not Available
15
Decal Dash Top White RH [6AK][EAK][EAKC][6AKC]
7178011
Not Available
15
Decal Hood Top Stripe Silver RH [EAZ][EAZC][6AZ][6AZC]
7177707
Not Available
15
Decal Hood Stripe Black LH [6AI][6AIC][6AK][EAK][EAKC][6AKC]
7177717
Not Available
15
Decal Hood Stripe Black RH [6AI][6AIC][6AK][EAK][EAKC][6AKC]
7177718
Not Available
15
DECAL HOOD SIDE STRIPE SILVER RH [6AZ][EAZ][EAZC][6AZC]
7179128
Not Available
15
Decal Dash Top White LH [6AK][EAK][EAKC][6AKC]
7178010
Not Available
15
DECAL HOOD SIDE STRIPE SILVER LH [6AZ][EAZ][EAZC][6AZC]
7179127
Not Available
15
Decal Hood Top Stripe Silver LH [EAZ][EAZC][6AZ][6AZC]
7177706
Not Available
16
Decal High Output LH [TH76AC][TH76ACC][TH76AG][TH76AGC][TH76AR] [TH76ARC][TH76AZ][TH76AZC][TY76AG][TY76AGC] [TY76AR][TY76ARC][TH76AA][TH76AK][TH76AO] [TY76AZ]
7176878
Not Available
16
Decal High Output Gold LH [TH76AB][TH76ABC][TH76AH]TH76AHC][TY76AB]
7176880
Not Available
16
Decal High Output RH [TH76AC][TH76ACC][TH76AG][TH76AGC][TH76AR] [TH76ARC][TH76AZ][TH76AZC][TY76AG][TY76AGC] [TY76AR][TY76ARC][TH76AA][TH76AK][TH76AO] [TY76AZ]
7176879
Not Available
16
Decal High Output Gold RH [TH76AB][TH76ABC][TH76AH]TH76AHC][TY76AB]
7176881
Not Available
17
DECAL-REFLECTOR AMBER
7175627
$23,09 Unit Price incl. VAT
18
Decal Tailgate EPS [AW][AZ]
7176730
Not Available
18
Decal Limited Edition [AE][AJ]
7176761
Not Available
19
DECAL EPS [EAU]
7175528
$18,89 Unit Price incl. VAT
20
Decal Dash Center Stripes White [6AK][EAK][EAKC][6AKC]
7178009
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
