1
Engine displacement
1000
2
Year
2020
3
Trim
RZR 1000 60 INCH EPS
4
Parts Catalog
OIL PUMP AND OIL COOLER
5
Parts Diagram
Parts Catalog
CRANKCASE AND CRANKSHAFT
by
ENGINE, STATOR AND COVER
OIL PUMP AND OIL COOLER
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
O-RING OIL PUMP
3610269
$17,84 Unit Price incl. VAT
1
PUMP OIL [INCLUDES O-RING]
3023124
$372,74 Unit Price incl. VAT
2
DOWEL HOLLOW OIL PUMP
7661975
$9,44 Unit Price incl. VAT
3
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
4
SCREW-SH-M6X1.0X16 8.8 ZPY D204
7519303
$7,34 Unit Price incl. VAT
5
SCR-M6X1.0X35 HX/FL-Y/D
7516827
$12,59 Unit Price incl. VAT
6
COOLER OIL TO WATER 7
1240820
$188,99 Unit Price incl. VAT
7
FILTER-OIL (10 MICRON)
2540086
$19,20 Unit Price incl. VAT
8
ADAPTOR-FILTER STRAIGHT
2521530
$68,24 Unit Price incl. VAT
9
PICKUP OIL PUMP WET SUMP
2521699
$89,24 Unit Price incl. VAT
10
CHAIN-OIL PUMP DRIVE G-90
3222191
3225043
$73,49 Unit Price incl. VAT
11
SCR-HXFL-M6X1.0X16 8.8 ZYL NYL
7519236
$6,29 Unit Price incl. VAT
12
O-RING .612X.818X.103
5413837
$9,44 Unit Price incl. VAT
13
SEAL-PICKUP
5415949
$10,49 Unit Price incl. VAT
14
WASHER-19X12X1.3 COPPER
5812232
$3,14 Unit Price incl. VAT
15
PLUG-SOCKET M12X1.5 DIN 908A
7052306
$31,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
