1
Engine displacement
780
2
Year
1996
3
Trim
SLT 780 - B964588
4
Parts Catalog
WATER INLET SLT 780 B964588 AND INTL. SLT 780 I964588 (4935683568B009)
5
Parts Diagram
Parts Catalog
WATER SIPHON SLT 780 B964588 AND INTL. SLT 780 I964588 (4935683568B008)
by
ELECTRICAL BOX SLT 780 B964588 AND INTL. SLT 780 I964588 (4935683568B010)
WATER INLET SLT 780 B964588 AND INTL. SLT 780 I964588 (4935683568B009)
1
STRAP PANDUIT 4 IN.(10)
7080483
Not Available
2
DESC NOT_AVAILABLE
8450058218
Not Available
3
BOLT S.S.(10)
7515155
Not Available
4
BOLT S.S.(10)
7515125
Not Available
5
BOLT SS(10)
7515126
$1,56 Unit Price incl. VAT
6
PLATE RIDE LONG ANGLED Substituted by 5630770
5630634
Not Available
7
INSERT RIDEPLATE
7010083
$10,70 Unit Price incl. VAT
8
GRATE INLET CAST BLK.
5630542067
$85,88 Unit Price incl. VAT
9
FITTING PILOT MOLDED
5431634
Not Available
10
GASKET PILOT
5810879
Not Available
11
WASHER FLAT S.S.(10) (.02)
7555848
Not Available
12
WASHER FLAT NYLON(10)
7555873
Not Available
13
NUT
7547003
Not Available
14
SCOOP INLET Substituted by 5630693
5130825
Not Available
15
O-RING PUMP HSG/HULL
5410652
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
