1
Engine displacement
800
2
Year
2019
3
Trim
800 AXYS PRO-RMK 163 SC / 3"
4
Parts Catalog
BUMPER, REAR, SNOWFLAP AND TAILLIGHT COVER
5
Parts Diagram
Parts Catalog
MIDDLE FAIRING
by
STEERING, SKI ASM.
BUMPER, REAR, SNOWFLAP AND TAILLIGHT COVER
1
1
1
1
1
1
2
3
4
5
5
6
6
6
6
6
6
6
6
6
6
6
6
7
8
9
10
10
10
10
10
10
11
11
12
12
12
12
12
12
13
14
15
15
16
17
1
COVER TAILLIGHT HARNESS 163 INDY RED
5259600293
$136,49 Unit Price incl. VAT
1
COVER TAILLIGHT HARNESS 163 ORANGE BURST
5259600647
$73,49 Unit Price incl. VAT
1
COVER TAILLIGHT HARNESS 163 INDIAN SKY BLUE
5259600737
$136,49 Unit Price incl. VAT
1
COVER TAILLIGHT HARNESS 163 LIME SQUEEZE
5259600630
$136,49 Unit Price incl. VAT
1
COVER TAILLIGHT HARNESS 163 NATURAL
5259600
$52,49 Unit Price incl. VAT
1
COVER TAILLIGHT HARNESS 163 BLACK
5259600067
$136,49 Unit Price incl. VAT
2
RIVET-4.8MM DIA-1.5-6.0 GRIP
7661973
$2,09 Unit Price incl. VAT
3
RIVET
7621433
$2,09 Unit Price incl. VAT
4
COVER TAILLIGHT BLACK
5452369070
$20,99 Unit Price incl. VAT
5
NUT-HXFL-M6X1.0 8 ZC NYL
7547487
$4,19 Unit Price incl. VAT
5
NUT-HXFL-M6X1.0 8 ZB3 NYL
7547453
$7,34 Unit Price incl. VAT
6
ASM. BUMPER REAR AL GBLK/ORBURST [SC SELECT OPTION][INCL. 2 9-11]
10178511697
$241,49 Unit Price incl. VAT
6
ASM. BUMPER REAR AL GBLK/ISKYBLU [SC SELECT OPTION][INCL. 2 9-11]
10178511696
$241,49 Unit Price incl. VAT
6
ASM. BUMPER REAR AL GBLK/LMSQZ [SC SELECT OPTION][INCL. 2 9-11]
10178511698
$241,49 Unit Price incl. VAT
6
ASM. BUMPER REAR CF INDIAN SKY BLUE [INCL. 7 8 10 11]
1017850737
$414,74 Unit Price incl. VAT
6
ASM. BUMPER REAR CF ORANGE BURST [INCL. 7 8 10 11]
1017850647
$430,49 Unit Price incl. VAT
6
ASM. BUMPER REAR AL GBLK/NAT [SC SELECT OPTION][INCL. 2 9-11]
10178511209
$241,49 Unit Price incl. VAT
6
ASM. BUMPER REAR CF INDY RED [INCL. 7 8 10 11]
1017850293
$414,74 Unit Price incl. VAT
6
ASM. BUMPER REAR AL GLSBLK [SC SELECT OPTION][INCL. 2 9-11]
1017851067
$241,49 Unit Price incl. VAT
6
ASM. BUMPER REAR CF BLACK [INCL. 7 8 10 11]
1017850067
$414,74 Unit Price incl. VAT
6
ASM. BUMPER REAR CF LEMON SQUEEZE [INCL. 7 8 10 11]
1017850630
$414,74 Unit Price incl. VAT
6
ASM. BUMPER REAR AL GBLK/IRED [SC SELECT OPTION][INCL. 2 9-11]
10178511695
$241,49 Unit Price incl. VAT
6
ASM. BUMPER REAR CF NATURAL [INCL. 7 8 10 11]
1017850309
$388,49 Unit Price incl. VAT
7
CAP BUMPER
5137460
$52,49 Unit Price incl. VAT
8
RIVET CHERRY Q BK
7662252
$2,09 Unit Price incl. VAT
9
SCR-TXPH-M6X1.0X25 8.8 ZOD
7519993
$2,09 Unit Price incl. VAT
10
MOUNT BUMPER IND SKY BLUE [SC SELECT OPTION]
5137501737
$73,49 Unit Price incl. VAT
10
MOUNT BUMPER IRED [SC SELECT OPTION]
5137501293
$83,99 Unit Price incl. VAT
10
MOUNT BUMPER ORBURST [SC SELECT OPTION]
5137501647
$89,24 Unit Price incl. VAT
10
MOUNT BUMPER GLSBLK [SC SELECT OPTION]
5137501067
$73,49 Unit Price incl. VAT
10
MOUNT BUMPER
5137501
$73,49 Unit Price incl. VAT
10
MOUNT BUMPER LMSQZ [SC SELECT OPTION]
5137501630
$73,49 Unit Price incl. VAT
11
TUBE BUMPER ALUMINUM [TUBE ONLY]
5339046067
$83,99 Unit Price incl. VAT
11
TUBE BUMPER CARBON
5336318
$173,24 Unit Price incl. VAT
12
ASM. CLOSEOFF TUNNEL MOUNT REAR LIME SQUEEZE
1021963630
$115,49 Unit Price incl. VAT
12
ASM-CLOSEOFF TUNNEL MOUNT REAR [COLOR OPTION]
1021963
$74,54 Unit Price incl. VAT
12
ASM. CLOSEOFF TUNNEL MOUNT REAR IND SKY BLUE
1021963737
$94,49 Unit Price incl. VAT
12
ASM-CLOSEOFF TUNNEL MOUNT REAR INDY RED [COLOR OPTION]
1021963293
$74,54 Unit Price incl. VAT
12
ASM. CLOSEOFF TUNNEL MOUNT REAR ORNG BURST
1021963647
Not Available
12
ASM-CLOSEOFF TUNNEL MOUNT REAR BLACK [COLOR OPTION]
1021963067
$104,99 Unit Price incl. VAT
13
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
14
RIVET
7621467
$2,09 Unit Price incl. VAT
15
FLAP-SNOW W/HOLES BLK
5456130070
$89,24 Unit Price incl. VAT
15
FLAP-SNOW
5451976070
2208364
$89,24 Unit Price incl. VAT
16
WSHR-5.3X10X1 ZB
7556071
$9,44 Unit Price incl. VAT
17
NUT-ACORN M5 BLK
7547286
$6,29 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
