DRIVE TRAIN, CLUTCH COVER AND DUCTING FOR RANGER XP 1000 EPS CREW NORHTSTAR FROM 2019

CHASSIS, MAIN FRAME AND SKID PLATES

HEADLIGHTS AND TAILLIGHTS

DRIVE TRAIN, CLUTCH COVER AND DUCTING

1

TANK FUEL Substituted by 2511323

5430968

Not Available

1

SEAL-OUTER CLUTCH COVER [TO 1/6/2021]

5416207

$68,24 Unit Price incl. VAT

2

BOLT-M6X1.0X20 PH/TX-OLIVE D

7518616

$2,09 Unit Price incl. VAT

2

GASKET-GAS CAP

5810144

$10,49 Unit Price incl. VAT

3

CAP GAS (BLACK)

5430725

$47,24 Unit Price incl. VAT

3

BRKT-SCREEN BELT

5264258

$52,49 Unit Price incl. VAT

4

COVER-CLUTCH INNER MACH [INCL. 5-9]

5142591

$414,74 Unit Price incl. VAT

4

COVER-CLUTCH INNER MACH [INCL. 5-9][TO 9/3/2018]

5140929

$414,74 Unit Price incl. VAT

4

Vent Tank

5431053

$47,24 Unit Price incl. VAT

5

BRKT-TRANSJOINT MAG MACH

5139822

$89,24 Unit Price incl. VAT

5

LINE VENT (38.0##) Substituted by 8360009-600

5521087

$83,99 Unit Price incl. VAT

6

DUCT-CLUTCH INLET

5416355

$167,99 Unit Price incl. VAT

6

BOLT

7512310

$4,19 Unit Price incl. VAT

7

Bracket Mounting Rear RH

5222155

Not Available

7

Bracket Mounting Rear LH

5222154

Not Available

7

DUCT-CLUTCH OUTLET

5416141

$167,99 Unit Price incl. VAT

8

SCREW(10)

7512208

$7,34 Unit Price incl. VAT

8

BOOT-HOSE ADAPTER

5454194

$47,24 Unit Price incl. VAT

9

BRKT R.TANK MT. Substituted by 5220916-067

5220916

Not Available

9

PLATE-INLET CLUTCH DUCT SEAL

5633909

$68,24 Unit Price incl. VAT

10

SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]

*******

Not Available

10

WASHER-.344X.688X.063 FL-Y

7558402

$1,56 Unit Price incl. VAT

10

K-CVR CLUTCH OTR RGR XP [INCL. 11 12 15 & DECAL]

2207560

$398,99 Unit Price incl. VAT

11

NUT-5/16-18 NYLOK-Y [INTL]

7542324

$1,56 Unit Price incl. VAT

11

O-RING-0.489X0.629X0.070 EPDM

5415647

$3,14 Unit Price incl. VAT

12

DUCT INLET DOWN TUBE

5431006

$132,29 Unit Price incl. VAT

12

PLUG-DRAIN 9/16-18 PP

5454915

$10,49 Unit Price incl. VAT

13

SCREW SELF-TAP(10)

7522004

Not Available

13

O-RING-2.25X2.625X.21 FKM

5416417

$25,19 Unit Price incl. VAT

14

LEVER FUEL

5431021

$9,44 Unit Price incl. VAT

14

MOUNT-OUTLET DUCT

5633826

$52,49 Unit Price incl. VAT

15

DECAL-BELT WARNING/CHECK

7177469

Not Available

15

SPRING LEVER COMPRESS.

7041209

$15,74 Unit Price incl. VAT

16

LEVER EXT. FUEL

5431020

Not Available

16

HOSE-JOINT

5416135

$83,99 Unit Price incl. VAT

17

HOSE-CLUTCH INLET TO TUNNEL

5416170

$115,49 Unit Price incl. VAT

17

CLAMP

7080236

$3,14 Unit Price incl. VAT

18

CLAMP-HOSE SLOTTED 75-90 DIA

7082314

$19,94 Unit Price incl. VAT

18

LINE FUEL (6 FT.)

5521204

Not Available

19

CLAMP-HOSE SLOTTED 92-100 DIA

7081969

$19,94 Unit Price incl. VAT

19

GASKET FUEL VALVE

5810308

Not Available

20

VALVE FUEL Substituted by 7051002

7052046

Not Available

20

SCR-HXFLG M6X1.0X25 10.9

7519754

$7,34 Unit Price incl. VAT

21

SCR-HXFL-M10X1.5X1.5 8.8 ZY3

7518531

$9,44 Unit Price incl. VAT

21

WASHER [INTL]

7558301

$2,09 Unit Price incl. VAT

22

SCR-M12X1.75X250 8.8 HX/FL ZOD

7518970

$41,99 Unit Price incl. VAT

22

SCR-TXBH-M12X1.75X110 8.8 SPC

7520945

$14,69 Unit Price incl. VAT

22

WASHER SPRING LOCK

7552801

$3,14 Unit Price incl. VAT

23

BOLT BLACK(10)

7512282

$2,09 Unit Price incl. VAT

23

SCR-TXBH-M12X1.75X245 8.8 SPC

7520946

$25,19 Unit Price incl. VAT

23

SCREW-HXFL-M12X1.75X120

7519794

$41,99 Unit Price incl. VAT

24

CLAMP-HOSE (LARGE GREEN)

7080307

$1,56 Unit Price incl. VAT

24

SCR-TXBH-M10X1.5X45 8.8ZOD P30

7520323

$10,49 Unit Price incl. VAT

25

NUT-HXFL M12X1.75 8 ZOD NYL

7547441

$9,44 Unit Price incl. VAT

25

FUEL LINE-50FT.PKG. Substituted by 8450003-1525

2870563

$136,49 Unit Price incl. VAT

26

FILTER

2530009

$12,59 Unit Price incl. VAT

26

WSHR-10.5X22.0X1.6 SPC

7556155

$9,44 Unit Price incl. VAT

27

O-RING-0.489X0.629X0.070 EPDM

5416606

$6,81 Unit Price incl. VAT

27

FITTING OUTLET DOUBLE

7052023

$36,74 Unit Price incl. VAT

28

WASHER-.510X.840X.031 Y

7555919

$7,34 Unit Price incl. VAT

28

TANK OIL

5430969

Not Available

29

HOSE-INTAKE DUCT

5416414

$73,49 Unit Price incl. VAT

29

RIVET-POP3/16(.251-.375)AL-LFB

7621457

$2,09 Unit Price incl. VAT

30

VENT-TANK

5430579

Not Available

31

GASKET OIL CAP

5810141

$4,19 Unit Price incl. VAT

32

CAP OIL TANK

5430779

$31,49 Unit Price incl. VAT

33

PAD SILENCER

5810423

Not Available

34

CLAMP HOSE Substituted by 7080684

7080374

Not Available

35

PAD

5810317

Not Available

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
