CHAINCASE 440 XCR 0961660 (4932113211B009) FOR 440 XCR - 0961660 FROM 1996

BRAKE 440 XCR 0961660 (4932113211B008)

DRIVE TRAIN 440 XCR 0961660 (4932113211B010)

CHAINCASE 440 XCR 0961660 (4932113211B009)

1

SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]

*******

Not Available

2

SEAL OIL

3610030

$36,74 Unit Price incl. VAT

3

SCR-HH-3/8-16X2.75GR5 ZY3

7515511

$7,34 Unit Price incl. VAT

4

NUT-3/8-16-Y

7542404

$3,14 Unit Price incl. VAT

5

BEARING W/O SEAL

3514304

$27,29 Unit Price incl. VAT

6

RING RETAINING

7718406

$11,54 Unit Price incl. VAT

7

SPACER SPROCKET

5010359

Not Available

8

SPKT 21T 11W 15T (11) 15T Spline

3221066

Not Available

9

BLOCK TIGHTENER [No Longer Available]

5630122

Not Available

9

TIGHTENER ASM GEARCASE Substituted by 1332213

1332096

Not Available

9

WHEEL C/C IDLER

5630123

Not Available

9

BEARING

3553002

$20,99 Unit Price incl. VAT

9

WASHER THRUST(10)

7558702

$3,14 Unit Price incl. VAT

9

PIN CHAIN TIGHTENER

7662210

Not Available

10

WASHER SPRING

7571620

$13,64 Unit Price incl. VAT

11

NUT

7542811

$10,49 Unit Price incl. VAT

12

PIN COTTER

7661401

$1,56 Unit Price incl. VAT

13

GASKET-CHAINCASE

5410277

Not Available

14

COVER CHAINCASE Substituted by 5630968

5630413

Not Available

15

SCR-1/4-20X1 1/4-TRIRD HX WH-Y

7512242

$4,19 Unit Price incl. VAT

16

SCREW(10)

7515350

$7,34 Unit Price incl. VAT

17

WASHER-SPRING CON 5/16X.090 Z

7571618

$11,54 Unit Price incl. VAT

18

WSHR-1.00X1.250X.120-Y

7555864

$4,19 Unit Price incl. VAT

19

SPROCKET 39 T

3222034

Not Available

20

CHAIN 66 PITCH

3224024

Not Available

21

NUT-HEX-3/8-16 A ZTB NYL

7542451

$2,09 Unit Price incl. VAT

22

PLUG

7052115

$10,49 Unit Price incl. VAT

23

CHAINCASE VENTED W/BRG CLEAR. Substituted by 5131568

5131121

Not Available

24

BOLT(10)

7515477

$52,49 Unit Price incl. VAT

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
