Parts Catalog
MAIN GEARCASE
5
Parts Diagram
Parts Catalog
FRONT HOUSING
by
SHOCK MOUNTING
MAIN GEARCASE
-
GEARCASE SHFT 4WD PRD INTL (Incl. 1-48 50-66)(FA)
1341336
Not Available
-
GEARCASE SHAFT 4WD 325 (Incl. 1-less 11)(AA)(CA)(FB)
1341296
Not Available
1
SEAL TRIPLE LIP
3233788
$57,74 Unit Price incl. VAT
1
SEAL
3233248
3233788
$57,74 Unit Price incl. VAT
2
SCREW
3233252
$9,44 Unit Price incl. VAT
3
Cover LH
3233763
Not Available
3
GEARCASE LH
3233610
Not Available
4
PIPE KNOCK
3233529
$16,79 Unit Price incl. VAT
5
BEARING
3233019
$54,59 Unit Price incl. VAT
6
SHAFT INPUT 31T
3233604
Not Available
6
Shaft Input 31T
3233756
Not Available
7
CHAIN SILENT 34P
3233036
Not Available
8
GEAR 16T
3233603
$132,29 Unit Price incl. VAT
8
Gear 14/19T
3233755
Not Available
9
BEARING BALL 6204 20 X 47 X 14
3233018
$47,24 Unit Price incl. VAT
10
NUT LOCK HEX FLANGE NYLON 5/16-24
3233961
$5,24 Unit Price incl. VAT
10
NUT
3233055
3233961
$5,24 Unit Price incl. VAT
11
WASHER
3233054
$12,59 Unit Price incl. VAT
12
BELLCRANK
3233153
$62,99 Unit Price incl. VAT
13
RING RETAINING BASIC EXTERNAL 0.75
3233045
$9,44 Unit Price incl. VAT
14
WASHER
3233040
$17,84 Unit Price incl. VAT
15
HOSE-POLY CLEAR 3/16 OD 1/8 ID
8360009600
$83,99 Unit Price incl. VAT
16
VENT
3233037
Not Available
17
SCREW TAPPING TORX PH 11902 X.50
3233749
$10,49 Unit Price incl. VAT
18
Switch 3 Position
3234019
Not Available
19
Gearcase Main
3233765
$1 268,39 Unit Price incl. VAT
19
GEARCASE RH
3233902
Not Available
20
PLUG OIL FILL
3233711
Not Available
21
Washer
3233872
$17,84 Unit Price incl. VAT
22
Washer
3233628
Not Available
23
Engagement Dog Low/Park
3233758
$185,84 Unit Price incl. VAT
23
Engagement Dog Low
3233732
$330,74 Unit Price incl. VAT
24
RING RETAINING BASIC EXT 0.938
3233306
$9,44 Unit Price incl. VAT
25
WASHER THRUST
3233619
$36,74 Unit Price incl. VAT
26
Gear 36T
3233760
Not Available
26
Gear 35T
3233631
$214,19 Unit Price incl. VAT
27
BEARING NEEDLE 25 X 29 X 10
3233103
$54,59 Unit Price incl. VAT
28
SHIFT FORK
3233602
Not Available
29
Shaft Reverse
3233761
Not Available
29
SHAFT REVERSE
3233598
Not Available
30
WASHER
3233012
Not Available
31
BEARING NEEDLE CAGE ASSY
3233014
$74,54 Unit Price incl. VAT
32
Sprocket 24T
3233599
Not Available
33
RING RETAINING
3233029
$10,49 Unit Price incl. VAT
34
Engagement Dog H/R
3234020
Not Available
35
GEAR 30T
3233600
$388,49 Unit Price incl. VAT
36
SPACER
3233613
$5,66 Unit Price incl. VAT
37
Gear Helical 36T
3233708
Not Available
37
GEAR-HELICAL.34T (FA)
3233762
Not Available
38
BRACKET INTERLOCK
3233309
$33,06 Unit Price incl. VAT
39
SPRING
3233032
$26,24 Unit Price incl. VAT
40
PIN INTERLOCK
3233308
Not Available
41
Screw
3233747
Not Available
42
Gear 50T
3233764
Not Available
42
Gear Helical 48T
3233709
Not Available
43
Screw
3233608
$9,44 Unit Price incl. VAT
44
Cover Bearing
3233609
Not Available
45
RING RETAINING BASIC EXTERNAL 0.984
3233106
$10,49 Unit Price incl. VAT
46
Bearing Ball
3233607
$60,89 Unit Price incl. VAT
47
Asm. Ground Spiral Bevel [Incl. 48]
3234912
Not Available
48
Fork Shift Low/Park
3233759
$330,74 Unit Price incl. VAT
48
SHIFT FORK LOW
3233605
Not Available
49
Switch 2 Position
3234001
Not Available
50
SPROCKET 12T
3233620
Not Available
51
Asm. Ground Spiral Bevel [Incl. 48]
3234912
Not Available
52
Shaft Output Rear
3233622
Not Available
53
THRUST BUTTON
3233582
$13,64 Unit Price incl. VAT
54
SHIM .450 X .265
3233583
$52,49 Unit Price incl. VAT
55
COVER OUTPUT
3233623
Not Available
55
Cover Output
3233781
Not Available
56
PLUG DRAIN Substituted by 3233777
3233253
$52,49 Unit Price incl. VAT
56
Plug Drain
3233777
$52,49 Unit Price incl. VAT
57
PLUG WASHER
3233254
$14,69 Unit Price incl. VAT
58
SHIM
3233611
$52,49 Unit Price incl. VAT
59
SHAFT OUTPUT MAIN FRONT
3233625
$262,49 Unit Price incl. VAT
60
SPROCKET (12T)
3233093
Not Available
61
ROLLER CHAIN 24P
3233626
Not Available
62
BEARING
3233552
$41,99 Unit Price incl. VAT
63
Shaft Shift
3233624
Not Available
64
Shaft Shift H/R
3233627
Not Available
65
O-RING
3233548
$52,49 Unit Price incl. VAT
66
Ring Retaining
3233618
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
