1
Engine displacement
600
2
Year
2005
3
Trim
600 / 800 SWITCHBACK F/O
4
Parts Catalog
WATER PUMP/OIL PUMP (800)
5
Parts Diagram
Parts Catalog
PISTON CRANKSHAFT (600)
by
CARBURETOR (800)
WATER PUMP/OIL PUMP (800)
1
2
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
PULLEY-WATERPUMP DRIVEN-17.00
3021044
$83,99 Unit Price incl. VAT
2
BEARING BALL SLD.DGRV.
3514311
Not Available
3
SHAFT-WATERPUMP 700BASE 17.00
5132273
$141,74 Unit Price incl. VAT
4
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
5
SEAL (Magneto)
3610044
$41,99 Unit Price incl. VAT
6
SEAL
3610067
3610433
$37,79 Unit Price incl. VAT
7
WASHER FLAT SS.(10)
7556006
$7,34 Unit Price incl. VAT
8
IMPELLER WATERPUMP
5432330
$40,94 Unit Price incl. VAT
9
WASHER
7555874
$4,19 Unit Price incl. VAT
10
NUT-HEX M8X1.25 NYLOCK-SS [S99CR]
7546804
$2,09 Unit Price incl. VAT
11
GASKET COVER WATERPUMP
5811627
Not Available
12
Cover
5631280
Not Available
13
FITTING 90DEG 1/2ID.HOSE Substituted by 7052312
7052221
Not Available
14
SCREW-M6X1.0X20-HX/FL-Y/D
7516822
$4,19 Unit Price incl. VAT
15
SCR-M6X1.0X25-HX/FL-Y/D
7516823
$5,76 Unit Price incl. VAT
16
LINE FUEL [BULK SVC]
8450061600
$115,49 Unit Price incl. VAT
17
CLAMP
7080603
$3,14 Unit Price incl. VAT
18
Pump Oil
2540102
Not Available
19
SCR-M5X.80X20-HX/FL-Y/D
7516607
$19,94 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
