1
Engine displacement
1000
2
Year
2018
3
Trim
RANGER XP 1000 EPS NORTHSTAR HVAC EDITION
4
Parts Catalog
AIR CONDITIONING ROUTINGS
5
Parts Diagram
Parts Catalog
AIR CONDITIONING DUCTING
by
CHASSIS, MAIN FRAME AND SKID PLATES
AIR CONDITIONING ROUTINGS
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
ASM-VALVE 3-WAY
2413634
2415244
$467,24 Unit Price incl. VAT
2
K-DRIER SERVICE
2207256
$194,24 Unit Price incl. VAT
2
CONDENSOR-HVAC RGR
2413821
$1 454,24 Unit Price incl. VAT
3
CLAMP-P .75X.28 HOLE RUBBER
7082364
$41,99 Unit Price incl. VAT
4
NUT-M6X1.0 FLG-NYLOC-OLIVE D
7547339
$2,09 Unit Price incl. VAT
5
HOSE-A/C CONDENSER LWR
5416547
$367,49 Unit Price incl. VAT
6
HOSE-HVAC RGR
5416213
$351,74 Unit Price incl. VAT
7
HOSE-HVAC RGR
5416214
$503,99 Unit Price incl. VAT
8
HOSE-HEATER ENG OUT TO 3 WAY
5416356
$83,99 Unit Price incl. VAT
9
HOSE-COOLANT 3WAY TO ENG
5416357
$62,99 Unit Price incl. VAT
10
HOSE-COOLANT 3WAY TO HEATER
5416359
$152,24 Unit Price incl. VAT
11
HOSE-HEATER RETURN
5416358
$29,39 Unit Price incl. VAT
12
BRKT-MNT 3WAY VALVE BLK
5263842329
$73,49 Unit Price incl. VAT
13
SCR-M6X1.0X20 HXHD FLG TDFM BK
7518529
$2,09 Unit Price incl. VAT
14
NUT-M6-1.0 U-TYPE (2.5-3.8)
7547674
$2,09 Unit Price incl. VAT
15
SPRINGBAND-CLAMP 27/12 GREEN
7080841
$13,64 Unit Price incl. VAT
16
CABLE-TIE DIA14-45MM DUAL-LOOP
7081807
$14,69 Unit Price incl. VAT
17
CLAMP-HOSE SPRING .81
7081026
$14,69 Unit Price incl. VAT
18
CLIP-ROUTING HVAC
5453897
$9,44 Unit Price incl. VAT
19
CLIP-ROUTING
7081496
$9,44 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
